9.3 Pin Out Table

RJ12
1 n/c
2 RX
3 TX
4 n/c
5 GND
6 n/c
Con 1
Pin Signal
1 n/c
2 RX
3 TX
4 n/c
5 GND
6 n/c
7 n/c
8 n/c
9 n/c
Chassis GND
Con 2
CONTROL IN/OUT (GPI/GPO)
Pin Signal
1 CMOS 1
2 CMOS 2
3 CMOS 3
4 CMOS 4
5 Open Collector 1
6 Open Collector 2
7 Open Collector 3
8 Open Collector 4
9 GND
10 n/c
11 GND
12 V +12V
13 GND
14 Vcc +5V
15 GND
Chassis GND
VIPdigital Manual 4.0 Yellowtec 2004 Rev. 26.07.2004
Frontpanel
RS232
PC-Link
Backplane
RS 232
PC-Link
In 1
In 2
In 3
In 4
Out 1
Out 2
Out 3
Out 4
Ground
Ground
For Test Only
Ground
For Test Only
Ground
Con 3 ANALOG-IN 1
1 GND
2 IN +
3 IN -
Chassis GND
Con 4 ANALOG-IN 2
1 GND
2 IN +
3 IN -
Chassis GND
Con 5 ANALOG LEFT-OUT
1 GND
2 OUT +
3 OUT -
Chassis GND
Con 6 ANALOG RIGHT-OUT
1 GND
2 OUT +
3 OUT -
Chassis GND
Con 7 ANALOG HYBRID-OUT
1 GND
2 OUT +
3 OUT -
Chassis GND
Con 8 DIGITAL AES/EBU-SYNC IN
1 GND
2 IN +
3 IN -
Chassis GND
Con 9 DIGITAL AES/EBU OUT
1 GND
2 OUT +
3 OUT -
Chassis GND
Page 61
In 1 / XLR3fem
In 2 / XLR3fem
Out Left /
XLR3male
Out Right /
XLR3male
Out Hybrid /
XLR3male
In AES/EBU /
XLR3female
Out AES/EBU /
XLR3male
