4.3.2.2 Analog Left Out and Right Out

(Con 5 / Con 6)
These two electronically balanced analog outputs in the XLR format provide the stereo-output signals
of the processor at line level. The reference of the analog outputs can be set using the
control within the VIPcon configuration software.
Note: VIPdigital is a one-channel design. Only the
signal. In all other cases audio signal of left and right channel are identical.

4.3.2.3 Analog Hybrid-Out

(Con 7)
This electronically balanced analog output in the XLR format provides the audio signal tapped after the
Input Module of VIPremote. The reference level of this output can be set, using the
control within the VIPcon configuration software.
The hybrid output transmits the "dry" input signal of the processor after a source selection and a level
adaptation, but before the subsequent "effect" signal processing with EQ, compressor and other
modules. This is designed to make an uncompressed and unprocessed signal available for a
connected telephone hybrid.

4.3.2.4 Digital AES/EBU-Sync/In

(Con 8)
This digital input corresponds to the AES/EBU standard and can be used as an audio signal input as
well as an external synchronization input. Since VIPdigital exclusively processes a single-channel
input signal, please decide on which of the two signals (L or R) of the two-channel AES/EBU input is to
be processed. Use the input select options of the
The reference level i.e. headroom setting for this input can be set using the
the VIPcon configuration software.
The Synchronisation option within the VIPcon configuration software allows a definition as whether
VIPdigital is to synchronized internally or to be synchronized externally via the digital signal (AES/EBU
audio signal or AES/EBU blank frame) applied to this socket. Since the digital input is equipped with a
sample rate converter, the processor may be internally synchronized even if digital audio signals are
processed.

4.3.2.5 Digital AES/EBU-Out

(Con 9)
This digital output complies with the AES/EBU standard and provides the stereo-output signals of the
processor. The reference level of the digital outputs can be set, using the
the VIPcon configuration software.
The reference level i.e. headroom setting for this output can be set using the
within the VIPcon configuration software.
Note: VIPdigital is a one-channel design. Only the
signal. In all other cases audio signal of left and right channel are identical.
VIPdigital Manual 4.0 Yellowtec 2004 Rev. 26.07.2004
Reverb Module in VIPremote produces a stereo
Input Module within the VIPremote software.
Reverb Module in VIPremote produces a real stereo
Output Levels
Output Levels
Input Levels control within
Output Levels control within
Output Levels control
Page 18
