4.1.5 Enter (5)

The Enter button activates the
different processor functions independently of the presets.
Pressing the button causes the display to show select ACTION
in its upper line and ESCAPE
LED of the Enter button will blink. If no other entry is made, the
mode will be terminated after a few seconds, and VIPdigital
returns to the normal operating mode. Turning the Selector
button on the right side of the Enter button selects the different
menu options of the Enter mode. Refer to the section
Mode for detailed information.

4.1.6 Selector (6)

The Selector is a rotary transducer used for selecting and
setting the menu options in the
pressing function which is identical to the function of the Enter
key. Therefore, you may also call the Enter mode by pressing
the Selector and select menu items there in the same way.
(Refer to the Enter Mode).

4.1.7 Card Slot (7)

The card slot is exclusively designed for an
acceptance of the SmartCard provided for
VIPdigital. Do not use no other storage media.
Please note that the gray double arrow of the
card points upwards as shown in the figure on the
right side, and points to the front to the unit (the
chip is on the bottom).
Note: There are no presets stored on the
YELLOWTEC SmartCard which is supplied with
the unit. Refer to Chapter
REMOTE SOFTWARE
data to your SmartCard.
Inserting a new SmartCard or a SmartCard with
non-valid data (e.g. data from the previous
version) will cause an error message on the
VIPdigital display: WRONG CARD or
FAULTY CARD.
When a SmartCard with valid data is inserted in the
name of the card holder, while the name of the internal preset still active can be viewed in the lower
line. At the same time, the LED of the Exit Preset button will blink. If one of the presets on the Smart
Card is loaded by pressing the
of the display will show the name of the card preset now activated.
Note: Use the VIPcon configuration software
SmartCard reading: Then a SmartCard preset will be activated as soon as the Card in inserted.
As another option you can disable SmartCard reading.
VIPdigital Manual 4.0 Yellowtec 2004 Rev. 26.07.2004
Enter Mode for configuring
below it. At the same time, the
Enter Mode. It has an additional
VIPremote – THE
for learning how to save
Preset Recall button, the lower line of the display will show the name
to configure VIPdigital for an alternative option of
Enter
Card Slot, the upper display line will show the
