6 CONNECT VIPdigital TO THE COMPUTER

6.1 Installing the connection

To use the two VIPcon and VIPremote applications included in the VIPdigital scope of delivery, a
serial connection must be established between your VIPdigital and your PC.
To establish a connection to your PC, use a standard serial cable (in the scope of delivery). Connect a
free serial port on your PC to the
Alternatively, you may use the serial
interface on the front panel
Control RJ12 of VIPdigital - e.g. for a
temporary connection to a laptop if
VIPdigital is installed in a 19" rack. As
an accessory your dealer can offer an
adapter on a 9-pin D-sub connector to
allow PCs with traditional serial
interface sockets to be connected.
If your PC is not equipped with a serial
port (as a number of laptop computers
are) but provides a free USB port you
may as well use a common USB to
serial converter.

6.2 Standard Application Start-up Procedure

1. Install the serial connection
2. If you were working with VIPremote or VIPcon before in off-line mode, exit both applications
3. Start VIPcon or VIPremote
4. VIPcon only (skip for VIPremote)
VIPcon provides password protection.
In the upcoming dialog window enter your password
or the default password
More information about VIPcon password protection see
Chapter VIPcon - The Configuration Software, section
Password Protection
5. That's all! VIPcon or VIPremote application window comes up. Now it is your turn to ...
Create Configuration setups with VIPcon
-
- Update the firmware of your VIPdigital with VIPcon
Control the sound settings of your VIPdigital with VIPremote in realtime
-
Create sound presets with VIPremote and save them to your VIPdigital, SmartCard
-
or your PC
Refer to the chapters VIPcon – THE CONFIGURATION
SOFTWARE or UPDATING VIPdigital
VIPdigital Manual 4.0 Yellowtec 2004 Rev. 26.07.2004
RS232 socket on the back panel of the unit.
Remote
dvp and click "OK".
for explicit decriptions.
SOFTWARE, VIPremote – THE REMOTE
Page 21
