7.10.1.1 Trigger Output Functions

List of the functions in the Trigger pulldown menu:
Disable
No function on this output
Button 1
Activates the trigger output when Preset 1 is selected
Button 2
Activates the trigger output when Preset 2 is selected
Button 3
Activates the trigger output when Preset 3 is selected
Button E
Activates the trigger output when the Enter mode is activated
Ready
Activates the control output shortly after readiness of operation is achieved.
Note: Trigger outputs are generated each time a change in preset selection takes place or enter mode is
activated. If for example button 1 is pressed repeatedly, this will not generate repeated trigger output
actions.

7.10.1.2 Trigger Output Actions

List of the signal form in the Action pulldown menu:
Tally
The control signal is active during the entire function duration
Pulse On
Activating the function generates a pulse. The pulse duration can be set in Pulse Duration.
Pulse Off
Terminating the function generates a pulse. The pulse duration can be set in Pulse Duration.
Pulse On/Off
Activating and terminating this function generates a pulse. The pulse duration can be set in Pulse
Duration.

7.10.2 Range: Pulse Duration

For the Pulse Trigger Output signal wave the Pulse duration can be set in the Pulse Duration pulldown
menu. Available pulse durations are
- 50 ms
- 100 ms
- 1000 ms
