7.10.3 Range: Trigger Inputs

VIPdigital provides 4 trigger inputs (GPIs).
The trigger inputs allow commands from other units to be received to initiate actions and/or functions
in VIPdigital. Thus, functions of your VIPdigital can be "controlled remotely".
Select a function available in the Action pulldown menu for each input.
A number of logic combinations with external applications results.
Refer to the

Trigger Input Actions

Refer to: Control-Out/In
among others. Refer to the chapter Technical Drawings / Descriptions for detailed connection
drawings under GPI/GPO Circuit
7.10.3.1 Trigger Input Actions
List of the actions and/or functions in the Action pulldown menu:
Disabled
A control signal on this input is ignored
Button 1
Activates in VIPdigital the same control command as if the Preset Recall 1 button was pressed
Button 2
Activates in VIPdigital the same control command as if the Preset Recall 2 button was pressed
Button 3
Activates in VIPdigital the same control command as if the Preset Recall 3 button was pressed
Button E
Activates in VIPdigital the same control command as if the Enter key was pressed
Input Mute
Performs an audio mute in the VIPdigital audio signal chain after the Input module. Use this
Trigger Input to connect a cough button.
VIPdigital Manual 4.0 Yellowtec 2004 Rev. 26.07.2004
list below for the functions available.
in the chapter Equipment Description / Backpanel, providing the technical data
examples.
Page 37
