7.9.5 Range: Read SmartCard

Select among the 3 SmartCard Read options:
Soft Read Enable
When your SmartCard is inserted, VIPdigital will not accept a preset until one of the Preset Recall
buttons is pressed.
Radical Read Enable
When the SmartCard is inserted, VIPdigital will accept the preset immediately. The preset number (1,
2 or 3) active prior to insertion will be accepted.
Disable
The data of an inserted SmartCard is ignored.

7.9.6 Range: Write SmartCard

Write enabled
Presets can be saved to the SmartCard (Save to SmartCard command/button enabled in the
VIPremote software)
Write disabled
Presets cannot be saved to the SmartCard (Save to SmartCard command/button disabled in the
VIPremote software.)

7.9.7 Range: Meter Default

Input Level
After an activation the Level Indicator will show the input level.
Output Level
After an activation the Level Indicator will show the output level.
Note: The Level Indicator shows the selections, using LEDs. The Level Indicator can be switched off
during operation at any time, using the
The Enter menu allows also switching between Input Level and Output Level.
Note: A Meter Mode setting performed on your VIPdigital is stored in a cap-buffered RAM for approx. 24
hrs. after the unit has been switched off. After this time VIPdigital will return to the selection set in
VIPcon.

7.9.8 Range: Enter Button

Checkbox: Function Disabled, No Access to Menu
Click on this checkbox to disable the Enter button.
Now, only the 3 internal presets or your SmartCard presets can be selected on VIPdigital.
All other controls are disabled.
VIPdigital Manual 4.0 Yellowtec 2004 Rev. 26.07.2004
Meter Mode menu item in the Enter menu of your VIPdigital.
Page 33
