4.2.3 State

This menu item is exclusively designed to display the valid scan rate (44.1 or 48 kHz). Entries are not
possible here. Proceed as follows:
1) Press the green Enter button or the Selector button to change to the Enter mode. The display
shows the select ACTION
2) Turn the Selector clockwise until the
3) Acknowledge the selection by pressing the Enter key or the Selector. Read the displayed scan
rate.
4) Wait for some seconds until the Enter mode is exited automatically, or press ENTER to
change to a higher level in the menu system to select another menu item.

4.2.4 Contrast

This option is designed for setting the display contrast. The control range is 0 to 100 %. Proceed as
follows:
1) Press the green Enter button or the Selector button to change to the Enter mode. The display
shows the select ACTION
2) Turn the Selector clockwise until the
3) Acknowledge the selection by pressing the Enter button or the Selector. Turn the Selector until
the display has a contrast which is convenient for you. View the display in a view angle which
is also relevant in later applications.
4) Wait for some seconds until the Enter mode is exited automatically, or press ENTER to
change to a higher level in the menu system to select another menu item.
Note: A contrast setting is stored in a cap-buffered RAM for approx. 24 hrs. after the unit has been
switched off. After this time VIPdigital will return to the default setting (100%).

4.2.5 Escape

This option is designed to exit the Enter mode. Turn the Selector to select a menu item and press the
Enter key or the Selector. The Enter mode is exited, and the LED above the Enter key extinguishes.
VIPdigital Manual 4.0 Yellowtec 2004 Rev. 26.07.2004
message and ESCAPE
STATE menu item is called.
message and ESCAPE
CONTRAST menu item is called.
below it.
below it.
