TECHNICAL INFORMATION

TECHNICAL INFORMATION

SPECIFICATIONS

THE SEQUENCER
4 synth tracks
1 FX track
1 CV/Gate track
128 patterns
Up to 64 steps per pattern
128 Sounds
128 Kits
16 Songs
6× arpeggiators
Individual track lengths
Swing, slide and accent functions
Track transpose
Micro timing
Parameter locks
Live friendly Performance mode
Sound-per-step change
Instant kit, pattern, track and Sound reload
Full real-time control
Full MIDI support
SEND EFFECTS
Wideshift Chorus
Saturator Delay
Supervoid Reverb
SYNTH VOICE (x4)
Fully analog signal path
2× analog oscillators
Variable waveshape on all waveforms
Oscillator AM and Sync modes
2× sub-oscillators
1× noise generator
1× 4-pole analog lowpass ladder filter
1× 2-pole analog multi-mode filter
1× analog overdrive circuit
Filter feedback
2× assignable LFOs
1× dedicated vibrato LFO
2× dedicated waveshape LFOs
1× amp envelope
2× assignable envelopes
2× dedicated LFO fade envelopes
1× dedicated noise fade envelope
1× dedicated vibrato envelope
1× dedicated autobend envelope
3x individual effect sends
ELECTRICAL SPECIFICATIONS
Impedance balanced audio outputs:
Headphones out level: +19 dBu (55
Main outputs level: +19 dBu
Ω
Output impedance: 440 unbalanced
Unbalanced audio inputs:
Input level: +19 dBu maximum
Ω
Audio input impedance: 9 k
Digital S/N ratio: 102 dBFS (20-20.000 Hz)
Unit power consumption: 8 W typical, 18 W maximum.
Recommended power supply: 6 V DC, 3 A
HARDWARE
122x32 pixel backlit LCD
MIDI In/Out/Thru with DIN Sync out
2 x 1/4" impedance balanced audio out jacks
2 x 1/4" audio in jacks
1 x 1/4" stereo headphone jack
2 x 1/4" dual CV/Gate outputs
48 kHz, 24-bit D/A and A/D converters
Flash-EEPROM upgradable OS
Electrically isolated USB 2.0 port
PHYSICAL SPECIFICATIONS
Steel casing
Dimensions: W340xD176xH63mm
(including knobs, jacks and rubber feet)
Weight: approximately 2.4 kg
POWER SUPPLY (PSU-3) ELECTRICAL SPECIFICATIONS
Input voltage range: 100-240V (43-60Hz)
Input connector: IEC320-C8 (2 prong)
In-rush current: 40-60 A maximum
Output voltage: 12 V DC
Output current: 2.5 A maximum
Output connector: 5.5x2.5mm DC plug, power at center
Ω
)
43
