18. TECHNICAL INFORMATION

ELECTRICAL SPECIFICATIONS
Impedance balanced audio outputs
Main outputs level: +15 dBu
Output impedance: 440 Ω unbalanced
Headphones output
Headphones out level: +15 dBu
Output impedance: 36 Ω
Audio inputs
Input level: +15 dBu
Audio input impedance: 11 kΩ
Unit power consumption: 12 W typical
Recommended power supply: PSU-3c,
12 V DC, 2A
HARDWARE
128 × 64 pixel OLED screen
MIDI In/Out/Thru with DIN Sync out
2 × 1/4" impedance balanced audio out jacks
2 × 1/4" audio in jacks
1 × 1/4" stereo headphone jack
48 kHz, 24-bit D/A and A/D converters
Electrically isolated hi-speed USB 2.0 port
Power inlet: Center positive 5.5 × 2.5 mm barrel jack,
12 V DC, 2A
PHYSICAL SPECIFICATIONS
Sturdy steel casing
Dimensions: W 215 × D 176 × H 63 mm
(8.5" × 6.9" × 2.5") (including knobs and feet)
Weight: approximately 1.53 kg (3.37 lbs)
100 × 100 mm VESA mounting holes. Use M4 screws
with a max length of 7 mm.
Maximum recommended ambient operating
temperature: +35˚C (+96˚F)
