PANEL LAYOUT AND CONNECTORS
•
Caution! Use only the bundled PSU-3 with your Analog Four. It can, using an appropriate power
cord, be used all over the globe without the need of voltage converters. Using the wrong type of
adapter may damage your unit. Damage caused by the use of incorrect power supply is not cov-
ered by warranty. Please see "TECHNICAL INFORMATION" on page 43 for details about the
Analog Four power supply.

ANALOG FOUR ACCESSORIES

RACK MOUNT KIT

When rack mounted, the Analog Four occupies four standard height units plus additional space, usually about 1
U, which is needed to accommodate cables plugged into the unit. A 1 U empty rack space below the Analog
Four is recommended for ventilation purposes.
When assembling the rack mount kit, make sure that you have a Phillips screwdriver of the right size. Use the
included M3x6 mm size screws to secure the rack mount consoles on each side of the Analog Four.

ECC-2 CARRYING BAG AND PL-1 PROTECTIVE LID

The carrying bag accommodates one Analog Four. The protective plastic lid is put on top of the Analog Four
panel and protects the LCD and the knobs. The protective lid is by default included with the bag.

CONNECTING THE UNIT

Before you start connecting the Analog Four to other units, make sure all units are switched off.
1. Plug the supplied DC adapter to a power outlet and connect the small plug to the 12 V DC connector of the
Analog Four unit.
2. Connect the main out L/R from the Analog Four to your mixer or amplifier.
3. If MIDI control of the Analog Four is desired, connect the MIDI OUT port of the device you wish send data
from to the MIDI IN port of the Analog Four. The MIDI THRU port "echoes" the data arriving at the MIDI IN
port, so it can be used for chaining MIDI units together.
4. Switch on all units.
