SNMP

The SLP family of products supports the Simple Network Management Protocol
(SNMP). This allows network management systems to use SNMP requests to
retrieve information and control power for the individual outlets.
The SNMP implementation includes an SNMP v1 agent supporting standard MIB I
and MIB II objects. A private enterprise MIB extension is also supported to provide
remote power control.
Note: For security, SNMP support is disabled by default.
Command
Set snmp
Set snmp getcomm
Set snmp setcomm
Set snmp trapdest1
Set snmp trapdest2
Set snmp traptime
Show snmp

Enabling and Setting up SNMP Support

SNMP support must be enabled and configured for access to private enterprise MIB
extensions for remote power control, and for generation of all SNMP traps.
Enabling/disabling SNMP support
The SNMP command is used to enable or disable SNMP support.
To enable SNMP support:
1. At the command prompt, type set snmp, followed by enabled or disabled
and press Enter.
Note: A restart is required after enabling or disabling SNMP support. See
Performing a warm boot
Setting trap destinations
The Set SNMP Trapdest1 and Trapdest2 commands are used to set the IP
addresses of SNMP management stations receiving all traps. A maximum of two
trap destinations are supported; one must be defined to enable trap generation.
To set the trap destination:
1. At the command prompt, type set snmp, trapdest1 or trapdest2, the
Ipaddress and press Enter.
Example
The following sets the trap destination 1 to 64.42.31.208:
SecureLinx SLP Remote Power Manager

Table 4-3. SNMP Command Summary

Description
Enables or disables SNMP support
Sets the 'get' community string
Sets the 'set' community string
Sets a destination IP addresses for traps
Sets a destination IP addresses for traps
Sets the delay for steady state condition
traps
Displays all SNMP configuration information
on page 40 for more information.
