2. On the subsequent Outlet Traps page, select or deselect the desired traps and
press Apply.

Tools

The Tools section contains access to rebooting the unit, uploading new firmware as
well as resetting the unit to factory defaults. This section is available to
administrative level users only.
Restart
Performing a warm boot:
1. Select the Restart from the Action drop-down menu and press Apply.
Note: System user/outlet/group configuration or outlet states are NOT
changed or reset with this command.
Resetting to factory defaults:
See
Resetting to Factory Defaults
defaults from the web browser interface.
Uploading new firmware:
See
Uploading Firmware
web browser interface.

Command Line Interface

Logging In

Logging in through Telnet/SSH requires directing the Telnet/SSH client to the
configured IP address of the unit.
Logging in through the Console (RS-232) port requires the use of a terminal or
terminal emulation software configured to support ANSI or VT100 and a supported
data rate (300, 1200, 2400, 4800, 9600, 19200, 38400, 57600, or 115200 BPS) - 8
data bits-no parity-one stop bit and Device Ready output signal (DTR or DSR).
To log in by RS-232 or Telnet/SSH:
1. Press Enter. The following appears, where x.xx is the firmware version:
Note: Logging in by Telnet will automatically open a session. It is not
necessary to press Enter.
2. At the Username and Password prompts, enter a valid username and
password. And press Enter.
You are given three attempts to enter a valid username and password
combination. If all three fail, the session ends.
SecureLinx SLP Remote Power Manager
for more information on uploading new firmware from the
SecureLinx Power Manager Version x.xx
Username:
for more information on resetting a unit to factory
3: Operations
24
