Setting the data rate for all serial/ ports:
1. Select the serial port data rate from the drop-down menu and press Apply.
Note: The default values are 9600 baud, 8 data bits, 1 stop bit, and no parity
(9600 N 8 1).
Creating a descriptive serial name:
1. Click on the Edit link in the Action column next to the port to be configured.
2. On the subsequent Serial Port Edit page, enter the descriptive name. Up to 24
alphanumeric and other typeable characters (ASCII 33 to 126 decimal, spaces
and colon characters are not allowed) are allowed. Press Apply.
Note: Port names '1' thru '64' and 'CONSOLE' are reserved system names
and may not be used.
Enabling or disabling serial port active signal checking:
1. Click on the Edit link in the Action column next to the port to be configured.
2. On the subsequent Serial Port Edit page, select On or Off from the DSR Check
drop-down menu and press Apply.
Outlets
The Outlets configuration page is used for assignment and/or editing of outlet
descriptive names and wakeup states.
Editing the outlet descriptive name:
1. Click on the Edit link in the Action column next to the outlet to be configured.
2. On the subsequent Outlet Edit page, enter the descriptive name. Up to 24
alphanumeric and other typeable characters (ASCII 33 to 126 decimal, spaces
and colon characters are not allowed) are allowed. Press Apply.
Changing the outlet wakeup state:
1. Click on the Edit link in the Action column next to the outlet to be configured.
2. On the subsequent Outlet Edit page, select On, Off, or Last from the Wakeup
State drop-down menu and press Apply.
Groups
The Groups configuration page is used for creation and deletion of group and
assignment of outlets to groups.
Creating a group:
1. Enter a descriptive group name in the Group Name field. Up to 24 alphanumeric
and other typeable characters (ASCII 33 to 126 decimal, spaces and colon
characters are not allowed) are allowed.
Removing a group:
1. Click on the Remove link in the Action column for the group to be removed and
press Yes on the subsequent confirmation window.
SecureLinx SLP Remote Power Manager
Press Apply.
