Available outlet and group power states may be set to on, off or reboot; the reboot
operation turns the outlet(s) off, delays for a period of 15 seconds and then turns the
outlet(s) on.
Individual
The Individual outlet control page displays all outlets assigned to the current user.
The user may apply on, off or reboot actions to individual, multiple or all accessible
outlets.
To apply actions to individual or multiple outlets:
1. In the Individual Outlet Control section, select the desired action from the Control
Action drop-down menu for each individual outlet to be changed and press
Apply.
To apply an action to all outlets:
1. In the Global Control section, select the desired action from the Control Action
drop-down menu and press Apply.
Group
The Group outlet control page displays all groups assigned to the current user as
well as the outlets for each group.
To select a group:
1. Select the group name from the drop-down menu and press Select. The page
will refresh to display all outlets associated to the selected group name.
To apply an action to a group:
Select the desired action from the drop-down menu and press Apply.
Outlet State
On
Off
Off
Off
On
Off
On
Off
On/Wait
Off/Wait
SecureLinx SLP Remote Power Manager

Table 3-1. Outlet State/Control State Field Values

Control State Description
On Outlet is on
Off Outlet is off
Pend On Outlet is off and about to turn on in
response to a sequence timer
Reboot Outlet is off and a Reboot action has
been initiated
Idle On A restart has occurred – Last Control
State has been maintained
Idle Off A restart has occurred – Last Control
State has been maintained
Wake On A power-loss has occurred –
Wakeup State has been applied
Wake Off A power-loss has occurred –
Wakeup State has been applied
Off Outlet state in transition – Re-query
of outlet status required
On Outlet state in transition – Re-query
of outlet status required
3: Operations
16
