6.1 Benefit of Web Pages
+
The Z web pages are useful for:
•
Reading the power supply model, identity, revision and LAN setup information
•
Configuring the LAN connection
•
Programming and reading the power supply DC output

6.2 Opening the HOME Page

Once the rear panel LAN Status LED has turned green (see Section 4.3), you may open the Z
page.
1. Read the IP address from the front panel (refer section 5.1 for details).
2. Open a web page browser program such as Internet Explorer. Enter the power supply IP
address as shown below. Click the "GO" button
The power supply Home page will appear. If it does not, refer to section 12 Troubleshooting.
3. Alternately, the hostname may be used for addressing the web page as shown below (if the
power supply is set for "DHCP/Auto-IP", and if the NetBIOS naming service is running on
the computer). See Section 4.5 for a description of the hostname.
The power supply Home page will appear. If it does not, refer to section 12 Troubleshooting.
6 WEB PAGES
