2.3 Installing cPCI-7841
What you have
In addition to this User's Manual, the package includes the follow-
ing items:
cPCI-7841 Dual Port Compact-PCI Isolated CAN Interface
Card
ADLINK CD-ROM
If any of these items is missing or damaged, contact the dealer
from whom you purchased the product. Save the shipping materi-
als and carton in case you want to ship or store the product in the
future.
cPCI-7841 Layout
Terminator Configuration
A 120 Ohm terminal resistor is installed for each port, while JP1
enables the terminal resistor for port0 and JP2 enables the termi-
nal resistor for port 1
Installation
9
