PM-7841 Specification Table
CAN Controller
CAN Transceiver
Signal Support
Isolation Voltage
Connectors
Operation Temperature
Storage Temperature
I/O port address
Memory Mapped Space
Power Consumption
(without external devices)
Introduction
Size
Table 1-2: cPCI-7841 Specifications
Ports
Humidity
IRQ Level
Size

Table 1-3: PM-7841 Specifications

132(L)mm x 98(H)mm
2 CAN channels (V2.0 A,B)
SJA1000
82c250/82c251
CAN_H, CAN_L
1000 Vrms
Dual 5 male connectors
°
0 ~ 60
C
°
°
-20
C ~ 80
5% ~ 95% non-condensing
Set by Jumper
Set by DIP Switch
128 Bytes by Software
400mA @5VDC ( Typical)
900mA @5VDC ( Maximum)
90.17(L)mm x 95.89(H)mm
C
5
