Saving Configuration - Draytek Vigor2110 Series User Manual

Name
Mode
Up Time
IP
GW IP
TX Packets
TX Rate
RX Packets
RX Rate
Note: The words in green mean that the WAN connection of that interface is ready for
accessing Internet; the words in red mean that the WAN connection of that interface is not
ready for accessing Internet.
2 . 6 S a v i n g C o
2 . 6 S a v i n g C o
Each time you click OK on the web page for saving the configuration, you can find messages
showing the system interaction with you.
Ready indicates the system is ready for you to input settings.
Settings Saved means your settings are saved once you click Finish or OK button.
Displays the name set in WAN1/WAN web page.
Displays the type of WAN connection (e.g., PPPoE).
Displays the total uptime of the interface.
Displays the IP address of the WAN interface.
Displays the IP address of the default gateway.
Displays the total transmitted packets at the WAN interface.
Displays the speed of transmitted octets at the WAN interface.
Displays the total number of received packets at the WAN interface.
Displays the speed of received octets at the WAN interface.
