4 . 1 5 D i a g n o s
4 . 1 5 D i a g n o s
Diagnostic Tools provide a useful way to view or diagnose the status of your Vigor router.
Below shows the menu items for Diagnostics.
4 . 1 5 . 1 D i a l - o u
4 . 1 5 . 1 D i a l - o u
Click Diagnostics and click Dial-out Trigger to open the web page. The internet connection
(e.g., PPPoE) is triggered by a package sending from the source IP address.
Decoded Format
Refresh
t i c s
t i c s
t T r i g g e r
t T r i g g e r
It shows the source IP address (local), destination IP
(remote) address, the protocol and length of the package.
Click it to reload the page.
224
Vigor2110 Series User's Guide
