Enable Inventory and Loop Modes

The CF RFID Reader Card has four reading modes, based on
different combinations of inventory mode and loop mode. The
chart below shows the results of enabling or disabling the modes.
Tag Select Loop
Mode Mode
One tag Disabled
One tag
Enabled
continuously
All tags
Disabled
present
All tags
Enabled
continuously
Note: Not all tag types are readable in Inventory Mode.
1. In the main screen of RFID Demo, tap RFID at the bottom of
the screen. In the pop-up menu, select adjust the Inventory
Mode and/or Loop Mode settings as desired.
2. After selecting the desired settings, tap Select Tags. The CF
RFID Reader Card will search for tags in range, according to
your settings.
CHAPTER 3: RFID DEMO
Inventory
Description
Mode
Disabled Selects the first tag in RF field
Selects the first tag continuously (the
Disabled same tag ID will be returned as long
as the tag remains in the RF field.
Inventory mode: returns the tag IDs
Enabled of all tags in the RF field and then
reports when there are no more tags.
Returns the tag IDs of all tags in the
RF field. It does not repeat a tag ID
Enabled
unless the tag goes out and then re-
enters the RF field.
29
