Socket CHS 7Xi User Manual

Bluetooth cordless hand scanner (chs) 2d and 1d barcode scanners
Hide thumbs Also See for CHS 7Xi:
Table of Contents

Advertisement

Quick Links

Socket
®
Bluetooth
Cordless Hand Scanner (CHS)
7Xi and 7XiRx
2D and 1D Barcode Scanners
User's Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CHS 7Xi and is the answer not in the manual?

Questions and answers

Related Manuals for Socket CHS 7Xi

Summary of Contents for Socket CHS 7Xi

  • Page 1 Socket ® Bluetooth Cordless Hand Scanner (CHS) 7Xi and 7XiRx 2D and 1D Barcode Scanners User’s Guide...

  • Page 2: Copyright Notice

    Other than the above, Socket Mobile can assume no responsibility for anything resulting from the application of information contained in this manual. Please refrain from any applications of the Socket Bluetooth Cordless Hand Scanner that are not described in this manual. Please refrain from disassembling the Bluetooth Cordless Hand Scanner. Disassembly of this device will void the product warranty.

  • Page 3: Table Of Contents

    ABLE OF ONTENTS COPYRIGHT NOTICE 1 INTRODUCTION 2 SCANNER SETUP 3 SETUP FOR WINDOWS PC 4 SETUP FOR WINDOWS MOBILE 5 SETUP FOR APPLE 6 SETUP FOR ANDROID 7 SETUP FOR BLACKBERRY APPENDICES A SPECIFICATIONS B SAFETY AND USAGE TIPS C BARCODE LABEL SPECIFICATIONS D DECODE ZONE E COMMAND BARCODES...

  • Page 4: Introduction

    1 | I NTRODUCTION Thank you for purchasing the Socket Bluetooth Cordless Hand Scanner (CHS), a portable handheld barcode scanner that is small, light, comfortable to use and enables you to scan data from 2D and 1D barcodes into a wide variety of computers, smartphones and PDAs.
  • Page 5  BlackBerry PlayBook See Socket website for list of compatible applications (coming soon). Alternatively, use SocketScan 10 SDK. Compatibility verified for latest models at time of testing. Other models or Bluetooth driver versions not tested. Other devices not tested with SocketScan 10 and may require the previous software version.
  • Page 6 LUETOOTH ODES The CHS 7Xi and 7XiRx support two kinds of Bluetooth connections: Human Interface Device (HID) and Serial Port Profile (SPP), each with its advantages and disadvantages. By default, the CHS is set to HID mode for Keyboard devices, which requires no software installation.
  • Page 7 Protective Carrying Case / Belt Holster SKU# TM-HS650-KT From Viziflex Seels Waterproof Skin SKU# SMS01 For more information on Socket accessories for the CHS, please visit: http://ww1.socketmobile.com/products/bluetooth-scanners/accessories-bt.aspx For more information on accessories from Taylor Made Cases, Viziflex Seels or other partners, please visit: http://ww1.socketmobile.com/products/star/custom-cases.aspx...
  • Page 8 ARDWARE EATURES Product Diagram Trigger button Status indicator LED Power button Protective rubber bumper Power connector (Remove rubber cap to access) CHAPTER 1: INTRODUCTION...
  • Page 9 ® Socket recommends using Sani-Cloth Plus brand disposable cloth wipes as the standard disinfectant wipe for the CHS 7XiRx. For more information about the wipes, please visit: http://www.pdipdi.com...
  • Page 10 5 minutes. Simultaneous Use of CHS and Socket Plug-in Device You can use the CHS and a Socket plug-in barcode / RFID / magnetic stripe reader simultaneously on the same host computer or device. However, you will need to run two different versions of SocketScan concurrently.

  • Page 11: Scanner Setup

    Accessories. WARNING: Do not remove or replace the pre-installed battery if you have an early version of the CHS 7Xi / 7XiRx. Check the first 4 digits of the Serial Number (S/N) labeled inside the battery compartment. If the number is less than 1135, then the battery should not be removed.
  • Page 12 TTACHING THE ETHER PTIONAL 1. Use a coin or screwdriver to unlock and remove the battery cover. Turn the lock underneath the scanner to a horizontal position to unlock. 2. Remove the battery cover. The Bluetooth Device Address (BDA) is printed on a label inside the battery compartment.

  • Page 13: Setup For Windows Pc

    Toshiba Bluetooth stacks. Due to the many device manufacturer and Bluetooth stack combinations, the CHS might not work correctly in SPP mode on some PCs. Socket highly recommends that you use the CHS in SPP mode. To learn more, read our white paper: http://www.socketmobile.com/pdf/techbrief/socketscan-10-...
  • Page 14 4. Use your computer’s Bluetooth software to connect to the CHS (see instructions on next page). In the device search, the CHS will appear as Socket 7Xi [xxxxxx] for the 7Xi / 7XiRx. The characters in brackets are the last six characters of the CHS Bluetooth Device Address (BDA), which is labeled inside the battery compartment.
  • Page 15 (Windows 7) click Add a Device. A device search will begin. 2. In the device list, select Socket CHS 7x or Socket 7Xi and click Next. 3. If prompted, select Enter the device’s pairing code and enter the passkey 0000 (four zeroes). Click Next.
  • Page 16 3. In the connection wizard, select Express Mode. Click Next. A device search will begin. 4. In the device list, select Socket 7Xi. Click Next. 5. If a passkey is requested, enter 0000 (four zeroes). Click OK. 6. Follow the remaining screens to complete the wizard.
  • Page 17 The CHS will beep once when it has connected and is ready to scan barcodes. The LED will also blink blue once every 3 seconds. To scan barcodes: 1. Open your application. Place the cursor where you want to enter data. 2.
  • Page 18 PTION SING THE To install SocketScan 10 software: 1. Access the SocketScan 10 installation file, either from the Socket website or the SocketScan 10 installation CD. • To install from a web download (recommended to ensure the latest software) − Open: http://www.socketmobile.com/support/downloads/data-collection/series7/ss10/...
  • Page 19 • Firefox: Click Save File. In the Downloads list, double-click SocketScan10Setup.exe. In the warning screen, click OK. • Chrome: Click Save at the bottom of the screen. Click on the link for the SocketScan10Setup.exe file. In the Security Warning screen, click Run. 3.
  • Page 20 Click Ports if a suitable incoming Bluetooth COM port is not listed and you would like to add one. Also, if SocketScan Settings lists multiple COM ports, you can determine if any are already paired to a Socket Bluetooth barcode scanner and/or which one is incoming.
  • Page 21 Properties. Click Advanced... Select Run as administrator and click OK. 2. Click on the SocketScan icon in the task tray . In the pop-up menu, click Socket EZ Pair. If the icon does not appear, click on the desktop shortcut for SocketScan 10 to launch the program.
  • Page 22 4. Power on the CHS. Press and hold the small power button until the LED turns blue and the CHS beeps twice (low-high). The LED blinks blue once per second to show that the Bluetooth radio is on but not connected. 5.
  • Page 23 3 seconds, and a CHS icon will appear in the task tray. 9. Click X to close Socket EZ Pair. The CHS registration screen will appear. If desired, register your CHS. CHAPTER 3: SETUP FOR WINDOWS PC...
  • Page 24 To scan barcodes: 1. Open your application. Place the cursor where you want to enter data. 2. Hold the CHS about 4 inches (10 cm) from the barcode and press and hold the trigger button. An aiming beam will appear for 3 seconds. Keep your hand steady while scanning.
  • Page 25 • Scanner settings – Utility lets you view Bluetooth properties, battery level, adjust beep / LED / vibrate settings, test barcodes, and more • Socket EZ Pair – Feature lets you scan an onscreen barcode to quickly pair the CHS with your computer •...
  • Page 26 SocketScan 10 Settings 1. Click on the SocketScan 10 icon in the task tray. In the pop-up menu, click SocketScan 10 Settings… 2. The SocketScan Settings screen will appear, reporting the manufacturer of the computer’s Bluetooth stack and the computer’s Bluetooth Device Address. •...

  • Page 27: Scanner Settings

    Scanner Settings You can access Scanner Settings only when the CHS is connected to your computer. 1. Click on the CHS icon in the task tray. In the pop-up menu, click Scanner settings… 2. The Scanner Settings screen will appear with an empty field. For the Microsoft and Broadcom (Widcomm) Bluetooth stacks, the CHS will also beep twice when it disconnects from SocketScan 10.
  • Page 28 5. The General properties screen will appear, reporting the Bluetooth friendly name, Bluetooth Device Address, Type of device, firmware version, and battery level. If desired, you can change the Bluetooth friendly name of the CHS. 6. Click on the Configuration tab. If desired, modify how the CHS confirms a good scan and/or select a suffix to automatically add to each instance of scanned data.
  • Page 29 If you want to read UPC-A symbols, disable the GS1 DataBar option so that GS1 DataBar symbols don’t get mistakenly decoded. Keep Data Matrix enabled so you can scan the onscreen barcode in Socket EZ Pair. 8. Click OK to exit the Scanner Properties. If desired, click Test to test scanning a barcode.
  • Page 30 About 1. Click on the SocketScan 10 icon in the task tray. In the pop-up menu, click About… 2. The About screen will appear, reporting information about your version of SocketScan 10. 3. After viewing the information, click OK to exit. CHAPTER 3: SETUP FOR WINDOWS PC...

  • Page 31: Setup For Windows Mobile

    36 keyboards • More efficient data communications for barcodes containing lots of data Socket highly recommends that you use the CHS in SPP mode. To learn more, read our white paper: http://www.socketmobile.com/pdf/techbrief/socketscan-10- sdk_white-paper.pdf. CHAPTER 4: SETUP FOR WINDOWS MOBILE...
  • Page 32 1: U HID M PTION SING THE To pair the CHS with your SoMo: You only need to pair the CHS with your SoMo the first time you try to connect. 1. Power on the CHS. Press and hold the small power button until the LED turns blue and the CHS beeps twice (low-high).
  • Page 33 4. Use the wireless manager to enable Bluetooth. 5. Tap Start | Settings | Connections tab | Bluetooth. 6. In the Bluetooth utility, tap Add new device… Alternatively, tap Add at the bottom of the screen. CHAPTER 4: SETUP FOR WINDOWS MOBILE...
  • Page 34 7. In the device list, tap Socket 7Xi. In the device search, the CHS will appear as Socket 7Xi [xxxxxx]. The characters in brackets are the last six characters of the CHS Bluetooth Device Address (BDA), which is labeled inside the battery compartment.
  • Page 35 To scan barcodes: 1. Open your application. Place the cursor where you want to enter data. 2. Hold the CHS about 4 inches (10 cm) from the barcode and press and hold the trigger button. An aiming beam will appear for 3 seconds. Keep your hand steady while scanning.
  • Page 36 2. Make sure Bluetooth is enabled on your PDA. 3. Access the SocketScan 10 installation file, either from the Socket website or the SocketScan 10 installation CD. • To install from a web download (recommended to ensure the latest software): −...
  • Page 37 4. Download and run the installation file. • Internet Explorer: In the Security Warning screens, click Run. When asked if you want to run the file, click Run. • Firefox: Click Save File. In the Downloads list, double-click SocketScan10Setup.exe. In the warning screen, click OK. •...
  • Page 38 6. Your computer will instruct you to check your mobile device for additional installation steps. Click OK. In the last screen of the wizard, click Finish. 7. Choose where you would like to install the software. Tap Install. 8. After installation, the PDA will report a soft reset is required. Tap Yes. To pair the CHS with your PDA: You only need to pair the CHS with your PDA the first time you try to connect.
  • Page 39 For more information about keyboard wedge and VIN decode options, please see SocketScan 10 Settings. . In the pop-up menu, tap Socket EZ Pair. 5. Tap the SocketScan icon in the Today screen 6. Tap 2D Scanner. CHAPTER 4: SETUP FOR WINDOWS MOBILE...
  • Page 40 7. Power on the CHS. Press and hold the small power button until the LED turns blue and the CHS beeps twice (low-high). The LED blinks blue once per second to show that the Bluetooth radio is on but not connected. 8.
  • Page 41 10. If prompted for a passkey, enter 0000 (four zeroes). Only devices running Bluetooth 2.0 will prompt for a passkey. 11. Your PDA will report that the pairing is complete. Click Done. The CHS will beep once after it has connected and is ready to scan barcodes. The LED will also blink blue once every 3 seconds, and a CHS icon will appear in the task tray in the Today screen.
  • Page 42 To scan barcodes: 1. Open your application. Place the cursor where you want to enter data. 2. Hold the CHS about 4 inches (10 cm) from the barcode and press and hold the trigger button. An aiming beam will appear for 3 seconds. Keep your hand steady while scanning. For example, try scanning the following barcode: After data is read and sent to the PDA, by default, the CHS will beep once and vibrate, the LED will flash green, and the beam will turn off.
  • Page 43 • Scanner settings – Utility lets you view Bluetooth properties, battery level, adjust beep / LED / vibrate settings, test barcodes, and more • Socket EZ Pair – Feature lets you quickly pair the CHS with your SoMo by scanning an onscreen barcode •...
  • Page 44 SocketScan 10 Settings You can only view Basic Scanner Properties when the CHS is connected to your SoMo. 1. Tap on the SocketScan 10 icon in the task tray. In the pop-up menu, tap SocketScan 10 Settings… 2. A screen will appear displaying the SocketScan software settings, as well as the Bluetooth stack manufacturer and Bluetooth Device Address.
  • Page 45 Scanner Settings You can access Scanner Settings only when the CHS is connected to your PDA. 1. Tap on the CHS icon in the task tray. In the pop-up menu, tap Scanner settings… 2. The Scanner Settings screen will appear with an empty field, and the CHS will beep twice.
  • Page 46 If you want to read UPC-A symbols, disable the GS1 DataBar option so that GS1 DataBar symbols don’t get mistakenly decoded. Keep Data Matrix enabled so you can scan the onscreen barcode in Socket EZ Pair. CHAPTER 4: SETUP FOR WINDOWS MOBILE...
  • Page 47 7. Tap ok to exit the Scanner Settings. If desired, tap Test to test scanning a barcode. 8. Scan a barcode that you would like information about. SocketScan will report the barcode’s symbology, data length, and data, in your choice of ASCII text or Hexadecimal format.
  • Page 48 About 1. Tap on the SocketScan 10 icon in the task tray. In the pop-up menu, tap About… 2. The About screen will appear, reporting information about your version of SocketScan 10. 3. After viewing the information, click ok to exit. CHAPTER 4: SETUP FOR WINDOWS MOBILE...

  • Page 49: Setup For Apple

    • More efficient data communications for page 53 barcodes containing lots of data • 10 hours of developer support included Socket highly recommends that you use the CHS in iOS mode. To learn more, read our white paper: http://www.socketmobile.com/pdf/techbrief/socketscan-10- sdk_white-paper.pdf.
  • Page 50 1: U HID M PTION SING THE To pair the CHS with your Apple device: You only need to pair the CHS with your Apple device the first time you try to connect. By default, the CHS is in HID mode for Keyboard devices. If you changed the CHS to a different mode, refer to the Command Barcodes to change it to the...
  • Page 51 3. In the device list, tap on Socket 7Xi. Tap Pair. In the device list, the CHS will appear as Keyboard, then as Socket 7Xi [xxxxxx]. The characters in brackets are the last six characters of the CHS Bluetooth Device Address (BDA), which is labeled inside the battery compartment.
  • Page 52 Simultaneous Scanning and Soft Keyboard Support: The CHS 7Xi and 7XiRx support simultaneous use of the barcode scanner and the onscreen keyboard while entering data into an application. This feature is enabled by default and can be modified by scanning a special command barcode.
  • Page 53 7Xi and 7XiRx. In iOS mode, the CHS can only scan barcodes into applications developed with the SocketScan 10 SDK. The CHS 7Xi and 7XiRx are made for the following Apple devices: o iPod touch (3rd-5th generation)
  • Page 54 The LED will also blink blue once every 3 seconds. If the CHS is listed as Socket 7Xi, the scanner is in HID mode. Scan the barcode on the previous page to configure it for iOS mode and restart the Bluetooth search.
  • Page 55 For example, try scanning the following barcode: After data is read and sent to the Apple device, by default, the CHS will beep once and vibrate, the LED will flash green, and the beam will turn off. By default, a carriage return is applied after scanned barcode data is entered. If no data is read in a few seconds, the beam will turn off, and you must try again.

  • Page 56: Setup For Android

    • Compatible with Android 2.1 to 4.x Socket highly recommends that you use the CHS in SPP mode. To learn more, read our white paper: http://www.socketmobile.com/pdf/techbrief/socketscan-10-sdk_white-paper.pdf. The instructions in this chapter are based on the Motorola Droid Pro running Android 2.2 in portrait mode.
  • Page 57 1: U HID M PTION SING THE Compatible with Android 2.2 to 4.x devices that support HID for Peripheral devices. To pair the CHS with your Android device: You only need to pair the CHS with your Android device the first time you try to connect.
  • Page 58 4. Make sure the device has Bluetooth on and is Discoverable. Touch Scan for devices. 5. In the list of found devices, select Socket CHS 7x or Socket 7Xi. 6. The CHS will beep once after it has connected and is ready to scan barcodes. The LED will also blink blue once every three seconds, and a Keyboard icon will appear next to the scanner listing.
  • Page 59 To scan barcodes: 1. Open your application. Place the cursor where you want to enter data. 2. Press the trigger button to scan a barcode. Make sure the aiming beam extends across the entire width of the barcode. For example, try scanning the following barcode: After data is read and sent to the phone/tablet, by default the CHS will beep once, the LED will flash green, and the beam will turn off.
  • Page 60 • Open Android Market and search for SocketScan. • In a web browser, open the Amazon Appstore for Android page: http://www.amazon.com/Socket-Mobile-SocketScan-CHS-Scanners/dp/B004X84VZA 2. Follow the onscreen instructions to download and install SocketScan 10 software. If prompted, allow the application to access Bluetooth connections and settings,...
  • Page 61 To pair the CHS with your Android device: You only need to pair the CHS with your Android device the first time you try to connect. 1. Make sure your Android device has Bluetooth on and is Discoverable. 2. Touch Home | Menu | Settings CHAPTER 6: SETUP FOR ANDROID...
  • Page 62 3. Touch Language and Keyboard or Locale and Text. Make sure SocketScan 10 is selected. 4. Open SocketScan 10 . For some devices, an icon will appear on the Home screen. For other devices, you may need to touch Menu and open Apps / Programs. 5.
  • Page 63 6. Touch Menu | Input Method. 7. Make sure SocketScan10 is selected. 8. Touch Menu | Socket EZ Pair. CHAPTER 6: SETUP FOR ANDROID...
  • Page 64 9. Touch 2D Scanner. 10. .Power on the CHS. Press and hold the small power button until the LED turns blue and the CHS beeps twice (low-high). The LED blinks blue once per second to show that the Bluetooth radio is on but not connected.
  • Page 65 If desired, swipe it down to open the software and register the scanner. After you have connected, you can touch Socket CHS 7x in the main screen of SocketScan 10 to view basic scanner properties.
  • Page 66 To scan barcodes: 1. Open your application. Place the cursor where you want to enter data. 2. Press the trigger button to scan a barcode. Make sure the aiming beam extends across the entire width of the barcode. For example, try scanning the following barcode: After data is read and sent to the phone/tablet, by default the CHS will beep once, the LED will flash green, and the beam will turn off.
  • Page 67 1. In the main screen of Scanner Settings, touch Socket CHS 7x or Socket 7Xi. 2. The screen will report the Bluetooth friendly name, scanner type, firmware version, and battery level of your CHS. To change the Bluetooth friendly name, touch Socket CHS 7x or Socket 7Xi.
  • Page 68 Configuration 1. In the main screen of Scanner Settings, in the menu, touch Configuration. 2. In the Configuration screen, enter any settings, as desired: • Good scan beep: Select to have the CHS beep to indicate that data was successfully decoded and transmitted to the Android device.
  • Page 69 If you would like to read UPC-A symbols, be sure to disable GS1 DataBar so that GS1 DataBar symbols don’t get mistakenly decoded. Keep Data Matrix enabled so you can scan the onscreen barcode in Socket EZ Pair. CHAPTER 6: SETUP FOR ANDROID...
  • Page 70 Test The Test feature reports the properties of a scanned barcode. 1. In the main screen of Scanner Settings, in the menu, touch Test. 2. In the Scan Window screen, select if you would like scanned data to appear as ASCII or hexadecimal format.

  • Page 71: Setup For Blackberry

    7 | S ETUP FOR LACK ERRY This chapter explains how to install and use the Bluetooth Cordless Hand Scanner (CHS) with one of the following BlackBerry devices: • BlackBerry® Bold 9700 Smartphone running BlackBerry OS 5.0.0.714 or later. Other models have not been tested with SocketScan 10 and may require a previous software version.
  • Page 72 HID M SING THE LACK ERRY Compatible with BlackBerry PlayBook running QNX. For BlackBerry OS smartphone, see page 75. To pair the CHS with your Android device: You only need to pair the CHS with your PlayBook the first time you try to connect.
  • Page 73 4. Make sure Bluetooth is turned ON. Tap Add New Device. 5. Tap Search. 6. In the list of found devices, select Socket 7Xi. 7. After they have paired and connected, the CHS will beep once. CHAPTER 7: SETUP FOR BLACKBERRY...
  • Page 74 To scan barcodes: 1. Open your application. Place the cursor where you want to enter data. 2. Press the trigger button to scan a barcode. Make sure the aiming beam extends across the entire width of the barcode. For example, try scanning the following barcode: After data is read and sent to the tablet, by default the CHS will beep once, the LED will flash green, and the beam will turn off.
  • Page 75 SPP M SING THE LACK ERRY To install the software: You can install SocketScan 10 software either by downloading directly to the phone or synchronizing to a host PC with BlackBerry Desktop Manager. Downloading to the Smartphone 1. Make sure your phone is connected to the Internet. 2.
  • Page 76 • Firefox: Click Save File. In the Downloads list, double-click SocketScan10Setup.exe. In the warning screen, click OK. • Chrome: Click Save at the bottom of the screen. Click on the link for SocketScan10Setup.exe. In the Security Warning screen, click Run. 3.
  • Page 77 1. In the Home screen, click Downloads | SocketScan 10. 2. If asked if you want to grant trusted application status, click Yes. 3. Click Menu | Socket EZ Pair. 4. When asked what kind of scanner you have, click 2D Scanner.
  • Page 78 8. When asked if you want to connect to the CHS, click Yes. The CHS will be referred to as Socket 7Xi [xxxxxx]. The characters in brackets are the last six characters of the CHS Bluetooth Device Address (BDA), which is labeled inside the battery compartment.
  • Page 79 To scan barcodes: 1. Make sure the CHS is powered on, the phone has Bluetooth turned on, and SocketScan 10 is running. 2. Open your application. Place the cursor where you want to enter data. 3. Hold the CHS about 4 inches (10 cm) from the barcode and press and hold the trigger button.
  • Page 80 10 S OCKET PECIAL EATURES SocketScan 10 software offers a variety of special features: • Scanner info – Provides information about your CHS. • Scanner settings – Utility lets you view scanner info, test barcodes, configure scanner beep / LED / vibrate behavior, configure a suffix, and enable/disable symbologies.
  • Page 81 Scanner Settings You can configure scanner settings only when the CHS is connected to your smartphone. 1. In SocketScan 10, click Menu | Scanner Settings. The CHS will beep twice, indicating a disconnection. 2. If prompted to connect to the CHS, click Yes. The CHS will beep once, indicating it has connected to your phone.
  • Page 82 Scanner Settings - Test 1. In the Scanner Settings screen, click Menu | Test. 2. Select if you would like to receive data in ASCII or hexadecimal format. 3. Scan a barcode. The Scan Windows will report the symbology, data length, and data content of the barcode you scanned.
  • Page 83 If you would like to read UPC-A symbols, be sure to disable GS1 DataBar so that GS1 DataBar symbols don’t get mistakenly decoded. Keep Data Matrix enabled so you can scan the onscreen barcode in Socket EZ Pair. CHAPTER 7: SETUP FOR BLACKBERRY...

  • Page 84: A Specifications

    *HID only versions of the CHS 7X and 7XRx (Revisions A-C) do not support SPP. ** Broadcom Bluetooth stack v1.8.0.6501 or v1.9.3 *** See Socket website for list of compatible applications (coming soon). Alternatively, use SocketScan 10 SDK. CHAPTER 7: SETUP FOR BLACKBERRY...

  • Page 85: Bluetooth Characteristics

    4.8 to 40.6 cm (1.9 to 16 inches) typical *Depends on symbol density, symbology, W-N Ratio, label media, and scan angle Direct Part Marking DPM and dot peen decoding mode supported by CHS 7Xi and 7XiRx (DPM) & Dot Peen Bluetooth Characteristics:...
  • Page 86 • Human bodies or containers of liquid positioned between the host and the Socket CHS. • The presence and activity level of competing Bluetooth, 802.11 (Wi-Fi) or other (proprietary) systems using the same 2.4 GHz frequency.

  • Page 87: B Safety And Usage Tips

    • Treat your product with care. Keep in a clean and dust-free place. • Changes or modifications of this product, not expressly approved by Socket, may void the user’s authority to operate the equipment. Antenna Care Do not place a metallic shield around the CHS as it will reduce the radio transmission efficiency.
  • Page 88 Driving RF energy may affect some electronic systems in motor vehicles, such as car stereo, safety equipment, etc. Check with your vehicle manufacturer to be sure that the CHS will not affect the vehicle’s electronics. Aircraft • Turn off your CHS before boarding any aircraft. •...

  • Page 89: C Barcode Label Specifications

    PPENDIX ARCODE ABEL PECIFICATIONS All barcode symbols/labels should satisfy the appropriate AIM Uniform Symbology Specification. Background Substrate: The barcode symbol should be printed on material (media) that is reflective and has a matte (not glossy) finish. A background diffuse reflectance of at least 70% to 80% is desirable for optimum contrast.

  • Page 90: D Decode Zone

    PPENDIX ECODE The decode zone for the CHS is shown below. The minimum element width (“X Dimension” or barcode “size”) is the width in thousandths of an inch (mils) of the narrowest element (bar or space) in the symbol. The figures shown are the typical scanning distances (depths of field) for selected barcode sizes.

  • Page 91: E Command Barcodes

    Configures the CHS as a Peripheral class device (optional for Windows and Android). iOS Mode Changes the CHS 7Xi or 7XiRx to Apple iOS mode (equivalent to SPP mode). Factory Defaults Factory Reset Configures the CHS to revert all settings to factory defaults. The CHS powers off after scanning this barcode.
  • Page 92 Bluetooth Connection Mode (ADVANCED Users Only) SPP Acceptor Mode Changes the CHS to Bluetooth Serial Port Profile (SPP) as an acceptor mode (waits for computer / device to initiate connection). SPP Initiator Mode Changes the CHS to Bluetooth Serial Port Profile (SPP) mode as an initiator. Use barcode generating software or website (e.g., http://barcode.tec-it.com) to create a barcode with the following data: #FNC SPP Initiator aabbccddeeff#...
  • Page 93 Enabled by Apple iOS Onscreen Keyboard Scan to Enable Scan to Disable Default WITH BEEP Configures the CHS to activate  the iOS onscreen keyboard when connected to an iOS NO BEEP device and the CHS power button is double-pressed. Enabled Good Scan Indicators Scan to Enable...
  • Page 94 Special Commands for HID Mode Scan to Enable WITH BEEP Scan to Enable NO BEEP Ctrl + Z Ctrl + A Shift + Tab Ctrl + S HID Keyboard Language Settings Scan to Enable Language English French German Spanish APPENDIX E: COMMAND BARCODES...
  • Page 95 1D S YMBOLOGIES Enabled by Scan to Enable Symbology Name Scan to Disable Default Codabar Code 93 / Code 93i Interleaved 2 of 5  EAN/UPC – UPC-E  EAN/UPC – UPC – A EAN/UPC – UPC-E1 APPENDIX E: COMMAND BARCODES...
  • Page 96 Enabled by Scan to Enable Symbology Name Scan to Disable Default  EAN/UPC – EAN 8 Standard 2 of 5 GS1 DataBar (RSS)  EAN/UPC – EAN-13  Code 128 / GS1 128  Code 39 Code 11 APPENDIX E: COMMAND BARCODES...
  • Page 97 2D S YMBOLOGIES Enabled Scan to Enable Symbology Name Scan to Disable by Default Aztec Data Matrix  (Required to scan onscreen barcode in Socket EZ Pair for SPP mode) MaxiCode QR Code MicroPDF417 MSI Code APPENDIX E: COMMAND BARCODES...
  • Page 98 Enabled by Scan to Enable Symbology Name Scan to Disable Default  PDF417 GS1 Composite – CC-A/B GS1 Composite – CC-C GS1 DataBar (RSS) Limited GS1 DataBar (RSS) APPENDIX E: COMMAND BARCODES...
  • Page 99 OSTAL YMBOLOGIES Enabled by Scan to Enable Symbology Name Scan to Disable Default Australian Post BPO 4-State Canada Post Dutch Post Infomail Japan Post APPENDIX E: COMMAND BARCODES...
  • Page 100 Enabled by Scan to Enable Symbology Name Scan to Disable Default Planet Postnet Sweden Post APPENDIX E: COMMAND BARCODES...
  • Page 101 CANNER ODES Note: Scanning multiple commands in a single instance will overwrite (not append) the previous command. Enabled by Scan to Enable Description Scan to Disable Default Factory Reset Configures the CHS to revert all  settings to factory defaults. The CHS wil power off after scanning this barcode.
  • Page 102 Enabled by Scan to Enable Description Scan to Disable Default Decode 1D and 2D Barcodes Configures the CHS to revert all  settings to factory defaults. The CHS wil power off after scanning this barcode. Decode in Bright Environment Enables the CHS to scan 1D and 2D barcodes in bright environment.
  • Page 103 – P DITING REFIX UFFIX You can configure the CHS to automatically add a suffix and/or prefix to each scan of data. Note: Scanning multiple commands in a single instance will overwrite (not append) the previous command. Enabled by Character or Command to Insert Scan to Enable Default ...

  • Page 104: F Special Button Sequences

    PPENDIX PECIAL UTTON EQUENCES ESTORING ACTORY EFAULTS To restore the CHS to its factory defaults, do the following: 1. Power on the CHS. 2. While pressing the trigger button, briefly press and release the power button. 3. After about 15 seconds, the CHS will beep. Release the trigger button. If you performed the actions correctly, the CHS will beep 5 times and power off.
  • Page 105 ETRIEVING CANNER AND IRMWARE NFORMATION 1. Power on the CHS and ensure the scanner is in Bluetooth HID mode by scanning the HID mode barcode in Appendix E. Note: If you are not sure of the current mode, scan the Factory Reset barcode in Appendix E and wait for the factory reset tone to play.

  • Page 106: G Cab Installation Instructions

    If you have the Socket SoMo running Windows Mobile 6 Service Pack 8 or later, SocketScan 10 is pre-loaded on the device. To install, in the Today screen, tap Getting Started and choose the option to install SocketScan 10.

  • Page 107: H Troubleshooting

    PPENDIX ROUBLESHOOTING – A ENERAL ROUBLESHOOTING SYMPTOM When I try to scan, I aim the scanner beam at the barcode, but no data appears on my screen, and the beam eventually turns off. POSSIBLE REASON SOLUTION The scanner is too close or too far from the Practice scanning at different distances and angles so you barcode or at an incorrect angle.
  • Page 108 SYMPTOM The Bluetooth device search has found multiple CHS devices, and I don’t know which one to choose. POSSIBLE REASONS SOLUTION The CHS is not paired with a host system, and Power off the CHS device(s) you do not want to there are multiple CHS devices in range.
  • Page 109 ROUBLESHOOTING FOR INDOWS SYMPTOM I am using the CHS in SPP mode and get the “Not connected” icon in the task tray in the Today screen and can’t trigger the scanner or scan any barcodes. POSSIBLE REASON SOLUTION Your PC is not connected to the CHS .
  • Page 110 Make sure the CHS is discoverable and connectable. In Bluetooth stack in Windows Vista when the Microsoft Bluetooth software, select the Socket CHS using a USB Bluetooth adapter. Bluetooth in the Bluetooth device list (its status may be shown as connection settings can sometimes become “Already Connected”), and click Next.
  • Page 111 You are trying to connect the CHS with an The first release of SocketScan 10 for Windows Mobile is HP iPAQ 100 or 200 series Pocket PC. only compatible with the Socket SoMo. Check back for HP iPAQ compatibility in future releases. SYMPTOM The Bluetooth software indicates that the CHS has connected, but when I try to scan data, it does not enter into my application.
  • Page 112 Windows Phone 7 is not compatible with Unless Microsoft adds support for HID or SPP to Windows the Bluetooth HID or SPP profile. Phone 7, you need to use a different device, such as the Socket SoMo. ROUBLESHOOTING FOR NDROID SYMPTOM The CHS won’t reconnect to my Samsung Galaxy or Dell Streak any more.
  • Page 113 ROUBLESHOOTING FOR LACK ERRY SYMPTOM When I perform a Bluetooth device search, the CHS does not appear in the found devices list. POSSIBLE REASON SOLUTION You are using the BlackBerry Storm 9530 or Upgrade your BlackBerry OS to version 5.00.714 or later. other smartphone with BlackBerry OS version previous to 5.00.714 SYMPTOM...

  • Page 114: I Technical Support

    PPENDIX ECHNICAL UPPORT If you have trouble installing or using the Bluetooth CHS, Socket has different support options to help you. Online Knowledge Base: Search for articles, Frequently Asked Questions or Hot Topics 24 hours a day. http://support.socketmobile.com/EU_S1a.asp Online Requests: Register your product and submit a question to our Technical Support Team.

  • Page 115: Limited Warranty

    Socket’s published specifications, liquid immersion, misuse or misapplication, damages caused by an act of God, nor as a result of service or modification other than by Socket unless specifically described by Socket in product documentation. This warranty does not provide coverage for any product updates, for example updates due to design changes, except as deemed necessary by Socket and does not cover any calibration or adjustments necessary for product functionality.

  • Page 116: Socketscan Software License Agreement

    License, whether on disk, print or electronic documentation, in read only memory, or any other media, are licensed to you by Socket Mobile, Inc. for use only under the terms of this License, and Socket Mobile reserves all rights not expressly granted to you. The rights granted herein are limited to Socket Mobile Inc's and its licensors' intellectual property rights in SocketScan Software and do not include any other patents or intellectual property rights.

  • Page 117: Regulatory Compliance

    Software. Socket Mobile’s entire liability and your exclusive remedy shall be, at Socket Mobile’s option, either (a) return of the price paid or (b) replacement of the Software which does not meet Socket Mobile’s limited warranty and which is returned to Socket with a copy of your receipt.
  • Page 118 2. In the unlikely event that there is electronic interference between this system and other wireless transmitters, quickly change the location of operation or stop operating the unit (cease signal transmission). 3. If other electrical interference or related problems occur, contact Socket technical support http://support.socketmobile.com/ Radio Frequency Interference Requirements This device complies with part 15 of the FCC rules.
  • Page 119 The user may find the following booklet helpful: How to Identify and Resolve Radio-TV Interference Problems. This booklet is available from the U.S. Government Printing Office, Washington, D.C. 20402. Canada Certification The marking of “IC:2394A-CHS1” on the device means: “2394A-CHS1” is the certification number, and the term “IC’...
  • Page 120 • Your device contains a factory installed rechargeable LI ion battery that should not be removed. Never throw the battery into a fire, as that could cause the battery to explode. • Never short-circuit the battery by bringing the terminals in contact with another metal object.
  • Page 121 © Socket Mobile, Inc. 1/2013 6410-000233 O...
