SerieS 7
1D LaSer quiCkStart guiDe
Model shown: CHS 7Mi
Bluetooth Barcode Scanner
CHS 7Mi, 7Pi
www.socketmobile.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CHS 7Mi and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Socket CHS 7Mi

Summary of Contents for Socket CHS 7Mi

  • Page 1 SerieS 7 1D LaSer quiCkStart guiDe Model shown: CHS 7Mi Bluetooth Barcode Scanner CHS 7Mi, 7Pi www.socketmobile.com...

  • Page 2: Package Contents

    Bluetooth SIG, Inc. USA, and any charging use by Socket Mobile, Inc. is under license. All other trademarks and trade names cradle contained herein may be those of their respective owners.

  • Page 3: Scanner Setup

    Lanyard (optional) detach the string loop of the Socket Mobile offers a Charging Cradle (op- tether from the lanyard. Then tional Accessory/sold separately) which is a feed the string loop through the slot...

  • Page 4: Basic Functionality

    BASIC fuNCTIONALITy BASIC fuNCTIONALITy (CONTINuEd) Aim the scan beam straight Not recommended across the entire barcode. scanning techniques Power button Scanning Barcodes: After connecting the CHS to your device, open an application and put the cursor where you want to enter data. • Powering On: • Powering Off/ Disconnecting: Hold the CHS about 4 inches (10 cm) from the barcode and press and...

  • Page 5: Connection Modes

    Application, please see pages 12-13 for the connection steps using MAC OS devices are connected using HId mode. iOS mode. Please visit the Socket Mobile App Store to confirm your Scanner-en- iOS devices are connected using either iOS mode or HId mode, but abled Application supports the CHS.
  • Page 6 3. Quickly double-press the power button of the CHS (like double- clicking a mouse) to open or close the onscreen keyboard. The CHS will beep once as confirmation. 3. Tap Socket CHS[xxxxxx] in the list of devices found. After a few sec- onds the “Not Paired”...
  • Page 7 CHS. Many applications include these steps and Bluetooth devices search will begin. barcodes in the set-up procedure. 3. Tap Socket CHS[xxxxxx] in the list of devices found. After a few If you are using an Application that connects to the CHS using HId seconds the “Not...
  • Page 8 4. You will be prompted to set SocketScan 10 as the keyboard language. do not scan onscreen. Touch Back . 2. In SocketScan 10, touch Menu | Socket EZ Pair. Touch Bluetooth. 5. Touch Home | Apps | Settings | Language & input. 3. Select Socket CHS [xxxxxx].
  • Page 9 ANdrOId - SErIAL POrT PrOfILE (SPP) WINdOWS - SErIAL POrT PrOfILE (SPP) To install the software and configure a COM port: The characters in brackets are the last 6 characters of the Bluetooth Address, which is labeled in the CHS battery Windows 7/8: Make sure you have administrative privileges to compartment.
  • Page 10 WINdOWS - HId (PErIPHErALS) MOdE to pair the CHS with the PC: (required only the first time you connect) 3. Select Socket CHS [xxxxxx]. If prompted for a passkey, enter 0000 (four zeroes). 1. Power on the CHS and scan this barcode. The CHS will beep 3 times.
  • Page 11 Bold 9700. Other phones may be compatible. grant trusted application status, click yes. to install the software: On your phone, open http://www. 5. Click Menu | Socket EZ Pair. Click 1D Scanner. If prompted, select socketmobile.com/blackberry. your CHS. follow the onscreen instructions to download and install the software.

  • Page 12: Bluetooth Unpairing

    CHS, it will be discoverable. remove the CHS from the Bluetooth list in your iOS device To unpair the CHS on your device, go to Settings > Bluetooth, tap next to the Socket CHS [xxxxxx] name, then tap “forget this device”.

  • Page 13: Bluetooth Connection

    BLuETOOTH CONNECTION COMMANd BArCOdES Scan command barcode(s) to quickly configure the CHS. Make sure the CHS is not connected to a device before scanning a command barcode! for a complete set of command barcodes, download the Command Barcodes Sheet: www.socketmobile.com/pdf/data-collection/ command-barcodes-sheet-7C.pdf The web link is also provided in the below Qr Code.
  • Page 14 COMMANd BArCOdES (CONTINuEd) COMMANd BArCOdES (CONTINuEd) Beep Settings Bluetooth Connection Modes Beep after CHS Decodes Data ON HiD-keyboard (default) (default) Configures the CHS to Human Interface device (HId) mode Enables CHS to beep as a Keyboard class device. to indicate success- ful scans.

  • Page 15: Status Indicators

    COMMANd BArCOdES (CONTINuEd) STATuS INdICATOrS Status Vibrate Settings LEd Activity Meaning Bluetooth 1 Blue blink every Bluetooth is On but not second connected. Vibrate after CHS Decodes Data ON (default) 1 Blue blink every 3 CHS is connected to Enables CHS to vibrate to seconds device.
  • Page 16 STATuS INdICATOrS (CONTINuEd) STATuS INdICATOrS (CONTINuEd) Beep Pattern Meaning Vibrate Meaning Low-high tone Power On Vibrate Power On or data successfully scanned. High-low tone Power Off 1 low beep Keyboard Pop-up Enable Command Barcodes are available on pages 19-20 to modify the 1 beep CHS connected to device and ready to scan bar- LEd, beep, and vibrate settings.

  • Page 17: Product Specifications

    Warranty Checker: 34.6 mm) http://www.socketmobile.com/support/warranty-checker Total Mass 3.2 oz (90.7 g) 1.6 oz (45 g) Socket Mobile Developer Program: Learn more at: http://www.socketmobile.com/developers Antimicrobial Antimicrobial additive in all external surfaces The user’s Guide (full installation and usage instructions) and Command Operating Temp +32 to +122°F (0 to + 50°C)

  • Page 18: Regulatory Compliance

    rEGuLATOry COMPLIANCE rEGuLATOry COMPLIANCE CE MArKING ANd EurOPEAN uNION COMPLIANCE This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. Testing for compliance to CE requirements was performed by an inde- pendent laboratory.

  • Page 19: Limited Warranty

    (1) year from the date of purchase. Product must be purchased new from a Socket Authorized distributor or reseller. used products and products purchased through non-authorized channels are not eligible for this warranty support.
  • Page 20 extend Your Warranty... receive Priority Service and Personal Care. you have 60 days from purchase date to enroll in a SocketCare Service Program! Please provide your device serial number from the label below when enrolling: Serial Label Here for detailed information visit: http://www.socketmobile.com/socketcare 2015 # 6430-00356 C...
