2.2.5 Network Connectivity, and Data Rate

When you plug in the Ethernet cable or power supply:
The square, green Link light above the Ethernet port indicates that the network connection has
been established (see
baud rate:
•
•
2.2.5.1 Verify Network Activity
The square, yellow Activity light blinks when there is network activity.
Operations Guide
Figure 2-9). The Link light changes color to confirm the auto-negotiated
This light is yellow at 10 Mbps.
It is orange at 100 Mbps.
930260E
Figure 2-9. Network Connector
