QuickSpecs

Configuration Information - Factory Integrated Models

NOTE: This section lists some of the steps required to configure a Factory Integrated Model. To ensure only valid configurations are
ordered, HP recommends the use of an HP approved configurator. Contact your local sales representative for information on CTO
product offerings and requirements.
NOTE: HP does not allow factory integration of options into standard models listed above.
Configure-to-order servers must start with a CTO Chassis.
NOTE: FIO indicates that this option is a Factory Installable Option.
Step 1: Base Server Blade Configuration
HP Models
Step 2: Choose Required Options (one of the following from each list unless otherwise
noted):
HP Processors
HP Memory
Step 3: Choose Additional Options for Factory Integration
HP Hard Drives
HP Integrity BL860c i2 Server Blade
NOTE: Adding Option code "#0D1" to the Server Blade PN will integrate the configured
blade into the enclosure (which must be on the same order).
Configurable Model ships with:
Four embedded 10 GB Ethernet NIC ports with Flex-10 support plus (1) additional
10/100 NIC dedicated to Integrity iLO 3 Management
Integrated HP Smart Array p410i SAS Controller for internal HDDs
Two small form factor (SFF) SAS hot plug hard drive bays
HP Integrity Integrated Lights-Out 3
NOTE: Select minimum one (1) and maximum two (2) processors.
Quad-Core Processors
HP BL8x0c i2 Itanium 9320 (1.33GHz/4-core/16MB/155W) Processor Kit
HP BL8x0c i2 Itanium 9340 (1.6GHz/4-core//20MB/185W) Processor Kit
HP BL8x0c i2 Itanium 9350 (1.73GHz/4-core/24MB/185W) Processor Kit
Dual-Core Processor
HP BL8x0c i2 Itanium 9310 (1.6GHz/2-core/10MB/130W) Processor Kit
NOTE: Select minimum one (1) (2x4GB DIMMs) module or two (2) (2x2GB DIMMs) per
server, and maximum of six (6) modules per server (12 modules if 2 processors
ordered)
HP BL8x0c i2 4GB (2x2GB) PC3-10600 Registered CAS 9 Memory Kit
HP BL8x0c i2 8GB (2x4GB) PC3-10600 Registered CAS 9 Memory Kit
HP BL8x0c i2 16GB (2x8GB) PC3-10600 Registered CAS 9 Memory Kit
HP BL8x0c i2 32GB (2x16GB) PC3-8500 Registered Memory Kit
NOTE: Memory Modules consist of pairs of DIMMs.
NOTE: DIMMs must be installed in pairs.
NOTE: Minimum memory requirement is 8GB.
NOTE: Hard drives have either a one year or three year warranty; refer to specific hard
drive QuickSpecs for details.
DA - 13624 Worldwide — Version 19 — April 18, 2014
HP Integrity BL860c i2 Server Blade
AD399A
AH386A
AH387A
AH388A
AH385A
AM326A
AM327A
AM328A
AM363A
Page 23
