Technical Specifications - HP Integrity BL860c i2 Quickspecs

QuickSpecs

Technical Specifications

System Unit
Embedded SAS RAID HP
Smart Array p410i
Controller
Dimensions
Shipping Dimensions
Weight
Temperature Range*
Relative Humidity**
* All temperature ratings shown are for sea level. An altitude derating of 1°C per 304.8 m (1.8°F per 1,000
ft) to 3048 m (10,000 ft) is applicable. No direct sunlight allowed. Upper operating limit is 3,048m (10,000
ft) or 70 Kpa/10.1 psia. Upper non-operating limit is 9,144 m (30,000 ft) or 30.3 KPa/4.4 psia.
** Storage maximum humidity of 90% is based on a maximum temperature of 45°C (113°F). Altitude
maximum for storage corresponds to a pressure minimum of 70 KPa.
Disk Drive and Enclosure
Interface
SAS Connectors
Cache Memory Speed
Server Interface
SAS Speed
Cache Memory
Logical Drives Supported Up to 2 logical volumes
Maximum Logical Drive
Capacity
Host Memory Addressing 64-bit, supporting greater than 4GB server memory space
RAID Support
Upgradeable Firmware
DA - 13624 Worldwide — Version 19 — April 18, 2014
Height
Depth
Width
Height
Depth
Width
Maximum
Operating
Non-Operating
Storage
Maximum Wet Bulb
Temperature
Operating
Shipping
Storage
3Gb SAS (Serial Attached SCSI)
2 internal (SFF8484) x4 wide part connectors
DDR2-800 memory provides up to 4.2 GB/s maximum bandwidth
X1 5.0Gbps PCIe provides 1GB/s maximum bandwidth.
Two x1 3G SAS provide 600MB/s maximum bandwidth.
Not supported.
Up to 64 logical
RAID 0 (Striping), RAID 1 (mirroring), and1+0 (Mirrored and Striped) (not
supported with BL8x0c i2 blades)
Upgradeable Firmware with Recovery ROM features
Online Drive Flash requires 256MB, 512MB, or 1GB cache module
HP Integrity BL860c i2 Server Blade
14.42 in (36.63 cm)
20.02 in (50.85 cm)
2.03 in (5.16 cm)
21.50 in (54.61 cm)
26.0- in (66.04 cm)
10.00 in (25.4 cm)
26.5 lbs (12.02 kg)
10° to 35° C (50° to 95° F)
-40° to 60° C (-40° to 140° F)
-20° to 60° C (-4° to 140° F)
30° C (86° F)
15% to 80%
10% to 90%
10% to 90%
Page 34
