Chapter 6 Customizing Cisco IP Communicator

PCM File Requirements for Custom Ring Types

OL-4698-01
The following example shows a RingList.xml file that defines two phone ring
types:
<CiscoIPPhoneRingList>
<Ring>
<DisplayName>Analog Synth 1</DisplayName>
<FileName>Analog1.raw</FileName>
</Ring>
<Ring>
<DisplayName>Analog Synth 2</DisplayName>
<FileName>Analog2.raw</FileName>
</Ring>
</CiscoIPPhoneRingList>
Related Topics
PCM File Requirements for Custom Ring Types, page 6-3
•
Configuring a Custom Phone Ring, page 6-4
•
The PCM files for the rings must meet the following requirements for proper
playback on Cisco IP Communicator:
Raw PCM (no header)
•
• 8000 samples per second
8 bits per sample
•
uLaw compression
•
Maximum ring size—16080 samples
•
Minimum ring size—240 samples
•
Number of samples in the ring is evenly divisible by 240.
•
Ring starts and ends at the zero crossing.
•
To create PCM files for custom phone rings, you can use any standard audio
•
editing packages that support these file format requirements.
