Chapter 7 Viewing Operational Information

Viewing Streaming Statistics Remotely

Table 7-8 Streaming statistics displayed on the device web page
Item
Domain
Remote Address
Local Address
Sender Joins
Receiver Joins
Byes
Start Time
Row Status
Host Name
Sender Packets
Sender Octets
Sender Tool
Sender Reports
Sender Report Time
OL-4698-01
A Cisco IP Communicator device can stream information to and from up to three
devices simultaneously. Cisco IP Communicator streams information when it is
on a a call or running a service that sends or receives audio or data.
The streaming statistics areas on the device web page provide information about
the streams. Most calls use only one stream (Stream 1), but some calls use two or
three stream. For example, a barged call uses Stream 1 and Stream 2.
Table 7-8 describes the items in the Streaming Statistics areas.
To display a Streaming Statistics area, access the web page as described in the
"Accessing the Web Page for a Device" section on page
Stream 1, Stream 2, or Stream 3.
Description
Domain of the device
IP address of the destination of the stream
IP address of the device
Number of times the device has started transmitting a stream
Number of times the device has started receiving a stream
Number of times the device has stopped transmitting a stream
Internal time stamp indicating when Cisco CallManager requested that the
device start transmitting packets
Whether the device is streaming
Host name of the device
Total number of packets sent by the device
Total number of octets sent by the device
Type of audio encoding used for the stream
Number of times this streaming statistics report has been accessed from the
web page (resets when the device resets)
Internal time stamp indicating when this streaming statistics report was
generated
Cisco IP Communicator Administration Guide for Cisco CallManager
Viewing Operational Information Remotely from a Web Page
7-10, then click
7-15
