Appendix 2 Media Specifi cations
Media, cont.

Tickets with Black Mark

a
e
f
g
c d
TICKETS
FEED
DIRECTION
70
a
Maximum:
Minimum (standard):
Minimum (Quick-Load):
b
Minimum:
Maximum:
c
b
Five fi xed positions (distance from inner edge of the media):
3 mm
8 mm
12 mm
16 mm
20 mm
d
The detectable width of the black mark should be at least 5.0 mm
(0.2 inches) on either side of the LSS detection point.
e
Maximum:
Common:
Minimum:
f
It is recommended that you place the black mark as close to the front
edge of the ticket as possible and use a negative Stop Adjust value to
control the media feed, so the tickets can be properly torn off.
Media Type Setup:
• Mark
The black mark should be non-refl ective carbon black on a whitish
background. Do not allow any perforations to break the edge of the
media as this may cause the media to split and jam the printer.
Intermec EasyCoder F2 – Installation & Operation IPL Version, Ed. 1
Media Width:
Copy Length:
LSS Detection Position:
(0.118 inches)
(0.315 inches)
(0.472 inches)
(0.639 inches)
(0.787 inches)
Black Mark Width:
Black Mark Length:
Black Mark Y-Position:
60.0 mm (2.36 inches)
25.0 mm (1.00 inches)
40.0 mm (1.57 inches)
20.0 mm (0.8 inches)
depends on DRAM size
21.3 mm (0.83 inches)
12.5 mm (0.5 inches)
5.0 mm (0.2 inches)
