Chapter 5
Thermal Transfer Printing
Ribbon Load
Important!
Save the label indicating the
sensitivity number attached to
the media roll. You will need
this number to set the media
sensitivity, see Appendix 2.
1
Open the side door.
30
The EasyCoder F2 can print on labels, tickets, tags, and continuous
stock using either direct thermal printing on special heat-sensitive
paper or thermal transfer printing using a special ink-coated ribbon.
For thermal transfer printing, the printer must be fi tted with an
optional transfer ribbon mechanism.
Thermal transfer printing makes it possible to use a wide range of
receiving face materials. Make sure to select a type of ribbon that
matches the type of receiving face material (see Appendix 2, "Media
Specifi cation") and to set up the printer accordingly (see Chapter
6. "Setting Up the Printer.")
The EasyCoder F2 can use transfer ribbon rolls wound with the
ink-coated side facing either outward or inward. Illustrations in this
manual show the ink-coated side facing inward.
Most transfer ribbons do not smear at room temperature.
2
Turn the printhead lift lever clockwise to raise
Intermec EasyCoder F2 – Installation & Operation IPL Version, Ed. 1
the printhead
