Tear-Off with
Quick-Load
(Straight-through)
Important!
Save the label indicating the
sensitivity number attached to
the media roll. You will need
this number to set the media
sensitivity, see Appendix 2.
1
Remove any empty core from the media supply
Intermec EasyCoder F2 – Installation & Operation IPL Version, Ed. 1
In addition to the media load procedure for tear-off (straight-through)
operation described earlier in this chapter, the EasyCoder F2 can
optionally be fi tted with a set of Quick-Load guides that makes media
load much easier and quicker, especially if the printer has a short side
door. See Chapter 8, "Options" for installation instructions.
The Quick-Load guides allow a media width as narrow as 40
mm (1.57 inches).
Quick-Load cannot be combined with peel-off (self-strip) opera-
tion.
roll post.
2
Fit a new roll of media on the supply post and
adjust the edge guide so the roll becomes fl ush
with the center section.
Chapter 4 Media Load
23
