MultiModemDID User Guide
Appendix B – Technical Specifications
Your MultiModemZBA-DID fax modem meets the following specifications:
Trade Name
Model Number
Fax
Standards:
Rates:
Error Correction:
Compression:
Conversion:
Commands:
Service Types:
Signaling Types:
Data
Rates:
Error Correction:
Data Compression:
Physical Description
Weight
Approvals
Modem Compatibility
Fax Compatibility
Flow Control
Command Buffer
Frequency Stability
Receiver Sensitivity
AGC Dynamic Range
Cables
Environmental
Limited Warranty
MultiModem™
MT5634ZBA-DID
Super G3 V.34/33.6K bps; V.17/14.4Kbps, V.29, V.27ter, V.21, T.30,
T.30 Annex A, T.30 Annex F, T.31, T.31 Annex B, T.32 Annex C,
TR29.2 Class 2 Recommendation
33.6K, 31.2K, 28.8K, 26.4K, 24K, 21.6K, 19.2K, 16.8K, 14.4K, 12K,
9600, 7200, 4800, 2400, 300 bps
V.42, ECM
MH (T.4), MR (T.4), & MMR (T.6)
Real time (on-the-fly) compression conversion
Class 1, 2, 1.0, 2.0, 2.1
Wink-start; immediate-start; delay dial
DTMF (1-7 digits accepted)
V.92/56K, V.90/56K, enhanced V.34/33.6K & others
V.42 & MNP®
V.44, V.42bis, MNP® Class 5
4.3" w × 1.0" h × 5.7" d; 8 oz
(10.9 cm × 2.5 cm × 14.5 cm; 227g)
224 g (8 oz)
EMC: FCC Part 15 Class B
Safety: UL, cUL, UL60950
Telecom: FCC Part 68, CS03
56K; ITU-T V.34 enhanced, V.34, V.32terbo, V.32bis, V.32, V.22bis,
V.22; Bell 212A and 103/113; ITU-T V.29, V.42, V.42bis; ITU-T V.21 &
V.23 in international versions
ITU-T Group 3, Class 1 and 2, T.4, T.30, V.21, V.27ter, V.29, V.17, and
TIA/EIA TR29.2
XON/XOFF (software), RTS/CTS (hardware)
40 characters
±0.01%
-43 dBm under worst-case conditions
43 dB
Two RJ-11s (LINE jack and PHONE jack)
One RJ-12 (DID line)
One DB9 (serial port)
Note: Any cables connected to the computer should be shielded to
reduce interference.
Temperature range 0°–50°C (32°–120°F); humidity range 20–90%
(non-condensing)
10 years
