MultiModemDID User Guide
Command:
Values:
Default:
Description:
Command:
Values:
Default:
Description:
Note: To stop a test, you must use the escape sequence (+++AT) before typing
&T0.
Command:
Values:
Description:
Command:
Values:
Default:
Description:
Command: &Z n=x Store Dialing Command
Values:
Default:
Description:
Command:
Values:
Default:
Description:
Chapter 4 - AT Commands, S-Registers, Result Codes
&S n Data Set Ready (DSR) Control
n = 0 or 1
0
&S0 DSR is always high (on).
&S1 DSR goes high only during a connection.
&T n V.54 Test Commands
n = 0, 1, 3 or 6
None
&T0 Abort. Stops any test in progress.
&T1 Initiates local analog loopback test.
&T3 Initiates local digital loopback test.
&T6 Initiates remote digital loopback test.
&V Display Current Settings
n/a
Displays the active modem settings, including the callback
security settings if callback security is enabled. If the setup
password has been entered, it also displays the callback
security passwords.
&W n Store Current Configuration
n = 0, 1
1
&W0 Stores current modem settings in nonvolatile memory and
causes them to be loaded in place of the factory defaults at
power-on or following the ATZ command. See also the &F
command.
&W1 Clears user default settings from nonvolatile memory and
causes the factory defaults to be loaded at power-on or
following the ATZ command.
n = 0, 1, 2 (callback security disabled)
x = Dialing command string
None
Stores dialing command x in memory location y . Dial the stored
number using the command ATDS= n . See also the #CBS n
command.
\A n Select Maximum MNP Block Size
n = 0, 1, 2, or 3
3
\A0 64-character maximum.
\A1 128-character maximum.
\A2 192-character maximum.
\A3 256-character maximum.
