Multitech MultiModem DID MT5634ZBA-DID User Manual page 24

MultiModemDID User Guide
Command: +DR= n V.44 Data Compression Reporting
Values:
Default:
Description:
Command: +DS44= n V.44 Data Compression
Values:
Default:
Description:
Chapter 4 - AT Commands, S-Registers, Result Codes
n = 0 or 1
0
Enables or disables the V.44 data compression report. If the
compression report is enabled, the +DR:< type > intermediate
result code reports the current DCE-DCE data compression type.
It is issued after the Error Control Report (+ER) and before the
final result code (e.g., CONNECT ). The intermediate result
code descriptions are shown after the command descriptions.
+DR=0 Disables the V.44 compression report.
+DR=1 Enables the V.44 compression report.
+DR=? Displays the allowed values.
+DR? Displays the current value.
+DR: NONE Data compression not in use.
+DR: V42B V.42bis is in use in both directions.
+DR: V44 V.44 is in use in both directions.
See description
See description
Controls the V.44 data compression function.
The command syntax is +DS44=[ direction ][,[0][,[0]
[,[ max_codewords_tx ][,[ max_codewords_rx ][,[ max_string_tx ]
[,[ max_string_rx ][,[ max_history_tx ][,[ max_history_rx ]]]]]]]]]<CR>
Subparameters that are not entered retain their current value.
Commas separate optional subparameters, and must be inserted
to skip a subparameter. Example: +DS44=,,,2048,2048<CR>
changes the maximum number of code words in both
directions, and keeps all other settings at their current values.
+DS44=? Reports supported options in the format (list of supported
direction values), (0), (0), (list of supported max_codewords_tx
values), (list of supported max_codewords_rx values), (list of
supported max_string_tx values), (list of supported max_string_rx
values), (list of supported max_history_tx values), (list of
supported max_history_rx values). Example: +DS44: (3, 0), (0),
(0), (256-2048), (256-2048), (31-255), (31-255), (512-11008),
(512-11008).
+DS44? Reports current options in the following format:
direction , 0, 0, max_codewords_tx , max_codewords_rx ,
max_string_tx , max_string_rx , max_history_tx , max_history_rx.
Example: +DS44: 3, 0, 0, 1024, 1024, 255, 255, 5120, 4096.
24
