2. On the Device Configuration page, you may enter values for the parameters indicated in
Table
Volume Settings
Use Digital Volume Control
Speaker Volume
Relay Settings
Activate Relay with DTMF Code
DTMF Activation Code
DTMF Activation Duration (in
seconds)
Activate Relay During Ring
Activate Relay During Night Ring Check this box to activate the relay for as long as a Night Ring tone is
Activate Relay While Call Active
Miscellaneous Settings
Beep on Initialization
Auto-Answer Incoming Calls
3. After changing the parameters, click the Save button.
Operations Guide
2-6.
Table 2-6. Device Configuration Parameters
Web Page Item
When selected, you can bypass the analog volume knob on the front
of the speaker. The volume level will only be determined by the digital
Speaker Volume setting on the Device Configuration page.
Type the desired speaker volume level into this field
(1 character limit).
When selected, the relay can be activated with a DTMF code.
Type the desired DTMF activation code (25 character limit).
Type the desired DTMF activation duration (in seconds) (1 character
limit).
NOTE: A DTMF activation duration of 0 will toggle the relay indefinitely
or until the activation code is sent again
When selected, the relay will be activated for as long as the call is
active.
NOTE: When the phone is set to Auto Answer, it will not ring and this
option does nothing.
ringing.
When selected, the relay will be activated for as long as the call is
active.
When selected, you will hear a beep when the speaker initializes.
When selected, the device will automatically answer incoming calls.
When Auto Answer is Off, the device will play a ringtone through the
speaker.
Click the Save button to save your configuration settings.
Note: You need to reboot for changes to take effect.
Click on the Test Audio button to do an audio test. When the Test
Audio button is pressed, you will hear a voice message for testing the
device audio quality and volume.
Click on the Test Relay button to do a relay test.
Click on the Reboot button to reboot the system.
930274L
Installing the VoIP V2 Speaker
Configure the Speaker Parameters
Description
