2.2.1.2 VoIP V2 Speaker (with PoE Injector) to a 802.3af Compliant PoE Switch
In Figure
separately). A PoE Injector is a power supply solution for those who have a standard Non PoE
Switch.
Operations Guide
2-2, if a PoE switch is not available, you will need a PoE Injector, part #010867A (ordered
Figure 2-2. VoIP V2 Speaker (with PoE Injector) to a Non PoE Switch
Non PoE Switch
PoE Injector (Part #010867A)
Cat 5 Ethernet cable
930274L
Installing the VoIP V2 Speaker
Device Configuration
VoIP V2 Speaker
