Mercedes-Benz Vito Operating Instructions Manual page 96

Controls
Seats
E press release button 1 and slide the
head restraint down until it is resting
on the backrest.
i
This position is not suitable when the seat
is occupied. It serves merely to improve the
field of vision to the rear when reversing (park-
ing). Before driving, the head restraints must
be pulled up again until they are heard to en-
3
gage in the detent. You can then adjust the
head restraints as described above.
Adjusting the head restraints electri-
cally
!
Do not adjust the height of the electrically
adjustable head restraint by hand. You could
otherwise damage the head restraint's mecha-
nism.
1 Electric head restraint height adjust-
ment
94
1 Manual head restraint height adjust-
ment
2 Manual angle adjustment
E
Slide the switch up or down in the di-
rection of arrow 1.
E
Adjust the angle of the head restraint
manually. To do this, pull or push the
bottom of head restraint 2.
To improve the driver's field of vision to
the rear when reversing (parking, rear
seats with comfort head restraints):
E
slide the switch down in the direction
of arrow 1 until the head restraint is
resting on the backrest.
i
This position is not suitable when the seat
is occupied. It serves merely to improve the
field of vision to the rear when reversing (park-
Nur fuer internen Gebrauch
ing). Before driving, adjust the head restraints
again as described above.
Removing the head restraints (manual
head restraint adjustment)
Standard seat
1 Release button
2 Height adjustment
E
Pull the head restraint up to the stop.
E Press release button 1 and pull out
the head restraint.
i
If the middle seat is not occupied, you can
remove the middle head restraint; this will pro-
vide a better view towards the rear.
