DMX
PROTOCOLS
1 -
Channel
1
3
Channel
1
2
3
4
C H A N N E L
Value
0 - 5
6 - 249
250 - 255
4
A N D
C H A N N E L
Value
0 - 5
6 - 255
0 - 255
0 - 5
6 - 255
Note: Enable channel 4 with Mode DIP switch no. 4 on.
0 - 5
6 - 42
43 - 85
86 - 128
129 - 171
172 - 214
215 - 255
D M X
M O D E
Percent
Function
0 - 1
Blackout
2 - 98
Flash rate, slow to fast
98 - 100
Continuous "Blinder" effect
D M X
Percent
Function
Flash intensity
0 - 1
Blackout
2 - 100
Minimum to maximum
Flash duration
0 - 100
0 - 650 ms @ 50 Hz AC, or
0 - 530 ms @ 60 Hz AC
Flash rate
0 - 1
No flash (single flash with ch. 1)
2 - 100
0.5 - 25 Hz @ 50 Hz AC, or
0.6 - 30 Hz @ 60 Hz AC
Special effects
0 - 1
No effect
2 - 16
Ramp up
16 - 33
Ramp down
33 - 50
Ramp up-down
50 - 67
Random
67 - 84
Lightning
84 - 100
Spikes
A
M O D E S
