REPARATION FOR USE

N P A C K I N G

The Atomic 3000 comes with the following items:

• Martin MAX-15 or MAX-7 xenon lamp (installed)

• Mounting bracket

• User manual

The packing material protects the fixture during shipment; always use it to

transport the fixture.

A C

The auto-ranging power supply automatically adjusts to any 50 - 60 Hz AC power

supply from 90 to 260 volts. No adjustment is necessary. Note that the MAX-15

lamp does not operate below 125 volts.

The current required by the Atomic 3000 varies according to lamp type, power

mode, and usage. To avoid overload, allow one 16 or 20 amp branch circuit per

fixture to operate the MAX-15 model at full power. Two fixtures may be placed

on a 16 amp branch circuit if they are operated in low power mode or use the

MAX-7 lamp.

Use 2.5 mm

possible.

To install a plug on the mains lead

The mains lead must be fitted with a heavy duty cord cap with ground connection.

Consult a qualified electrician if you have any doubts about proper installation.

P O W E R C O N N E C T I O N

(13 AWG) or larger power feed cables and keep runs as short as

Preparation for use

Atomic 3000 user manual
