Simple on/off remote control of the fixture can be achieved by connecting a
switch or relay to pins 1 and 3 of one of the data input sockets. Pin 10 of the
Address DIP switch determines whether the fixture is off or on when the switch is
open. See Table 3.
Multiple fixtures can be controlled from the same switch if they are serially
connected output-to-input. Do not terminate the link.
18
/
O F F
Switch open (off)
Switch closed (on)
Table 3: Remote stand-alone control
Stand-alone operation
Pin 10 ON
Pin 10 OFF
ON
OFF
OFF
ON
Atomic 3000 user manual
