Figure 1: Ambient Light Immunity - Opticon OPR 3201 Specification Manual

Conditions
Barcode Sample: OPTOELECTRONICS Test Sample
PCS:
Resolution:
Symbology:
Quiet zone:
N/W ratio:
Distance:
Angle (see note below):
Curvature:
Power supply voltage:
Direct light or specular reflection from a light source should be prevented from entering
the acceptance area.
Note: α, β and γ respectively represent pitch, skew and tilt. Please see section 8 for how
these values are defined.

Figure 1: Ambient light immunity

0.9
0.25 mm
9-digit Code 39
10 mm
1:2.5
70 mm
Α = 0° β = 15° γ = 0°
R = ∞
6.0 V (RS-232C)
5.0 V (Wedge/USB)
9
