3. Physical Features
3.1. Dimensions
W 56.0 x D 108.1 x H 148.6 mm
3.2. Weight
78.0 g ±5 g (max.), excluding the cable
4. Environmental Specifications
4.1. Operating Temperature and Humidity
Temperature: -5 to 50° C
Humidity: 5 to 95%
4.2. Charging Temperature
Temperature: 0 to 40° C
4.3. Storage Temperature and Humidity
Temperature: -20 to 60° C
Humidity: 5 to 95%
4.4. Ambient Light Immunity
Decoding performance is guaranteed when the range of illumination on a barcode
surface is between zero and the following values:
Incandescent light
Fluorescent light
Sunlight
3,000 lx
3,000 lx
50,000 lx
8
Opticon
OPR 3201
Specifications Manual
