OPERATION
Broadcasting to All Projectors!
On the IR remote or wired keypad, press to display the projector box. Press again without
entering a number - the keypad commands will now affect all projectors.
Make certain that only one projector has its "Broadcast Keys" option selected (checked) - the
remaining projectors should have the option unchecked and their keypads disabled (do this in
Preferences menu). The "Broadcast Keys" projector will then relay keypad commands to the
others. If using a wired remote, make sure to select the "Broadcast Keys" option for the projec-
tor to which the wired remote is connected.
NOTE: If you are using a computer or controller to issue commands, use the correct RS-232
software command to broadcast.
3.9

Error Conditions

Occasionally the projector may encounter an error condition that interrupts normal operation.
Such a condition can be caused by an invalid user entry, an input signal error (most common)
or other system error.
If you would like to be notified on-screen of such errors, select the "Screen" option from the
"Display Error Messages" pull-down list (in Preferences menu). If you would like to be notified
via a serial communication only, select the "RS-232" option instead. To receive both notifica-
tions, select "All". To disable error messages (except for invalid user entries), select "Off".
NOTE: Error messages also always appear at the rear LCD next to the keypad.
User Errors ! Invalid User Entry
Any keypad entry not recognized by the projector will trigger an on-screen error message
describing the problem. For example, if you specify a channel number that has not been
defined, the message "Invalid Channel" will appear. Or if you try to enter the wrong password,
you'll see "Invalid Password". Press
message box.
NOTE: Displaying of "Invalid User Entry" messages cannot be disabled, even if Display Error
Messages has been set to "Off".
Input Signal Errors!
Input signal errors messages appear when there are no menus present, and have selected an
input on which the projector detects a problem. While menus remain operational and pressing
any key will temporarily remove the message from the screen, you must resolve the signal
problem in order to permanently eliminate the message.
NOTE: Input signal messages appear on-screen only if Display Error Messages has been set to
"Screen" or "All".
No Signal
The message "No signal" appears when there is no signal detected at the selected input. Both
HSYNC and VSYNC are inactive and the screen background is black. Connect or correct the
signal, or select another input.
or to confirm the message and eliminate the
Enter
Exit
3-41
