Color
Color
Press
Color
to adjust the color saturation level, i.e. the amount of color in a video image. Lower
settings produce less saturated colors - a setting of "0" produces a black and white image, for
example. If the color level is too high, colors will be overpowering and unrealistic. Use
and
until the desired color saturation level is displayed. This is not used when an RGB
source is input.
Tint
Tint
Press
to adjust the red/green color hue for true color reproduction of NTSC video signals.
Tint
For best results, adjust tint while displaying a proper test pattern - otherwise, it is recommended
that tint remain at its default setting. Use
This is not used when an RGB source is input.
Detail
Detail
Detail
Press
to adjust the sharpness of a video image (it is of limited use for non-video). Use
and
above 3 will also introduce a certain degree of noise in the image. Set below 3 to filter the sig-
nal and remove noise from a noisy source. This is not used when an RGB source is input.
Contrast
Cont
Press
Cont
Use
and
remain bright but not distorted or tinted (i.e., "crushed").
Brightness
Bright
Press
to increase or decrease the amount of perceived light in the image so that black just
Bright
changes to very dark gray. Use
Adjusting the Image (Image Settings subsection). Avoid "crushing", or distorted blacks and/or
whites.
Volume
Vol
Press
Vol
to control the audio level. Use
Projector
Proj
Press
when you want to access a specific projector within a group or if you simply need to
Proj
see if the local projector is listening. The number appearing in the "Enter Number" window
indicates which projector is currently listening to commands, and will match the projector num-
ber that has been defined in its Preferences menu.
The "Projector" checkbox (read-only) shows whether or not the projector physically connected
to a keypad is listening to commands from that keypad. A checkmark means that connected
projector is listening; if there is no checkmark, you are communicating with a different projec-
tor.
!
+
Mute*
+
Mute*
!
+
OSD*
+
OSD*
until the display is as sharp as desired, keeping in mind that any level of detail
to increase or decrease the difference between light and dark areas of your image.
until you reach the desired level of contrast, making sure that the whites
turn the audio and menu display on
ON
=
turn the audio and menu display off
=
OFF
turn the menu system on
=
ON
turn the menu system off
=
OFF
and
until the desired tint is displayed.
and
until you reach the desired level. See 3.6,
and
until you reach the desired volume.
3-7
OPERATION
