OPERATION
Figure 3.16. Preferences Menu
Image Orientation
Choose from Front, Rear, Inverted Front, Inverted Rear according to your installation. If the
setting is incorrect, the image will be reversed and/or upside down. See 2.6, Operating
Orientation for an illustrated explanation.
Keystone
Non-functional in this version of software.
Language
This projector displays menu and help text in English only.
Display Channel List
Enter a checkmark if you want to see a scrollable channel list whenever you press
from
Chan
your presentation (note that each channel to be included in the list must also be tagged in the
"In Menu" checkbox in the Channel Setup menu). This option also enables on-screen feedback
when using the
key. If you prefer to hide the channel list and input dialog box while
Input
switching channels and sources during a presentation, do not enter a checkmark.
NOTE: The Channel List and input dialog box cannot be hidden when a menu is displayed.
Display Slidebars
Enter a checkmark to superimpose a small slidebar over the current image when an adjustable
parameter is selected directly with a key (the option does not affect slidebars in menus). These
"direct" slidebars include volume, contrast, brightness, position, pixel tracking and phase, and
others. If "Display Slidebars" is unchecked, these slidebars will be hidden during adjustment.
Display Error Messages
Choose in what way you want to be notified of errors detected in either the incoming signal or
projector. Select "Screen" or "All" if you want a brief message displayed. If you prefer to be
notified via a serial communication only (RS-232 or RS-422), select "RS232" instead. To dis-
able error messages entirely (except invalid user entries), select "Off".
NOTE: Display of invalid user entries cannot be disabled, even if you choose the "Off" option.
3-29
