SPECIFICATIONS

Inputs:
(1) Component, (1) S-video, (1) Composite, (1) Pass-through
Input standards: NTSC (PAL, NTSC export version)
Output formats: 1024 x 575 (anamorphic), 768 x 575 (wide screens), 1024 x 768 (4:3 screens)
Bandwidth:
Video inputs: 0-5.5 Mhz
Pass-through: 100 Mhz
Power input:
120V (220V export model), 50/60 Hz
Power
consumption:
15W
Control Options: RS-232, Infrared, Front panel
Operating
environment:
41-95° F (5-35° C)
0-90% humidity (non-condensing)
Dimensions:
Width: 17.45 in./443.23 mm
Depth: 16 in./406.40 mm
Height: 3.5 in./88.90 mm
Weight:
16 lbs./7.26 kg
Safety
Regulations:
Complies with UL, FCC class 'B', CE, C-tick
Fuses:
(Screen Fuse: 5mm x 25mm, AGC, 1A, 250v, Fast Blow)
(Main Fuse: 5mm x 20 mm, 500mA, 250v, Slow Blow)
Rack Ears:
Included
Supplied Accessories
• Remote Control w/ 2 AAA Batteries
• Power Cord
• Users
Manual
6-20
