ATTENTION: Pour réduire les risques d'incendie, utiliser uniquement des conducteurs de
télécommunications 26 AWG au de section supérleure.

AT Commands and Fax Developer Guides

AT Commands and Fax Class 1 and Class 2 Developer Guides for this product are published in separate
documents. You can download these from the Multi-Tech Installation Resources website at
www.multitech.com/setup/product.go.

Technical Specifications

Your MultiModem II modem meets the following specifications:
Trade Name
Model Number
Server-to-Client Data
Rates
Client-to-Client Data
Rates
Fax Data Rates
Data Format
Commands
Command Buffer
Modem Compatibility
Fax Compatibility
Error Correction
Data Compression
Speed Conversion
Mode of Operation
Flow Control
Transmission Level
Frequency Stability
Receiver Sensitivity
AGC Dynamic Range
Connectors
Cables
Indicators
Speaker
Manual Controls
Multi-Tech Systems, Inc. MT5600BA-V92 User Guide
MultiModem® II
MT5600BA
V.92/56K speeds when accessing a V.92 server
(actual speed depends on server capabilities and line conditions)
33600, 31200, 28800, 26400, 24000, 21600, 19200, 16800, 14400, 12000,
9600, 7200, 4800, 2400, 1200, 0-300 bps
14400, 12000, 9600, 7200, 4800, 2400, 300 bps
Synchronous and asynchronous
AT Commands, V.25bis
60 characters
V.92, V.90, 56K, V.34 enhanced, V.34, V.32terbo, V.32bis, V.32, V.25bis,
V.22bis, V.22; Bell 212A and 103/113; V.42, V.42bis; V.21 & V.23 in
international versions, V.44
V.17/14.4K, Group 3, Class 1, 1.0, 2
V.42
V.44 (6:1 throughput), V.42bis, MNP Class 5 (2:1 throughput)
Serial port data rates adjustable to 300, 1200, 2400, 4800, 9600, 19200,
38400, 57600, 115200, and 230400 bps
Fax online modes; full duplex over dial-up and two-wire or four-wire leased
lines; data mode, command mode, online command mode, V.54 test mode
XON/XOFF (software), RTS/CTS (hardware)
-11 dBm (dial-up—varies depending on country or region for which the
modem is set), -10 dBm (leased-line)
±0.01%
-43 dBm under worst-case conditions
33 dB
One DB25F (RS-232C/D) connector; three RJ-11s
Three modular telephone cords (USA); country- or region-specific cordage for
International models; one 9-pin to 25-pin serial cable for International
models; external power supply
Note: Any cables connected to the computer should be shielded to reduce
interference.
32-character backlit LCD for status and configuration information; LEDs for
Transmit Data, Receive Data, Carrier Detect, Off Hook, Terminal Ready, and
Test Mode
1-inch speaker for call progress monitoring
Power switch, speaker volume control, four LCD control buttons
Chapter 3 – Using the Front Panel
6
