Safety Warnings

●
Use this product only with UL- and CUL-listed computers.
●
To reduce the risk of fire, use only 26 AWG or larger telephone wiring.
●
Never install telephone wiring during a lightning storm.
●
Never install a telephone jack in a wet location unless the jack is specifically designed for wet
locations.
●
Never touch uninsulated telephone wires or terminals unless the telephone line has been
disconnected at the network interface.
●
Use caution when installing or modifying telephone lines.
●
Avoid using a telephone during an electrical storm; there is a risk of electrical shock from lightning.
●
Do not use a telephone in the vicinity of a gas leak.
●
This product must be disconnected from the telephone network interface when servicing.

AT Commands and Fax Developer Guides

AT Commands and Fax Class 1 and Class 2 Developer Guides for this product are published in separate
documents. You can download these from the Multi-Tech Installation Resources website at
www.multitech.com/setup/product.go.

Technical Specifications

Your MultiModem II modem meets the following specifications:
Trade Name
Model Number
Server-to-Client Data
Rates
Client-to-Client Data
Rates
Fax Data Rates
Data Format
Commands
Command Buffer
Modem Compatibility
Fax Compatibility
Error Correction
Data Compression
Speed Conversion
Mode of Operation
Flow Control
Transmission Level
Frequency Stability
Multi-Tech Systems, Inc. MT5600BA-V92 User Guide
MultiModem® II
MT5600BA
V.92/56K speeds when accessing a V.92 server
(actual speed depends on server capabilities and line conditions)
33600, 31200, 28800, 26400, 24000, 21600, 19200, 16800, 14400, 12000,
9600, 7200, 4800, 2400, 1200, 0-300 bps
14400, 12000, 9600, 7200, 4800, 2400, 300 bps
Synchronous and asynchronous
AT Commands, V.25bis
60 characters
V.92, V.90, 56K, V.34 enhanced, V.34, V.32terbo, V.32bis, V.32, V.25bis,
V.22bis, V.22; Bell 212A and 103/113; V.42, V.42bis; V.21 & V.23 in
international versions, V.44
V.17/14.4K, Group 3, Class 1, 1.0, 2
V.42
V.44 (6:1 throughput), V.42bis, MNP Class 5 (2:1 throughput)
Serial port data rates adjustable to 300, 1200, 2400, 4800, 9600, 19200,
38400, 57600, 115200, and 230400 bps
Fax online modes; full duplex over dial-up and two-wire or four-wire leased
lines; data mode, command mode, online command mode, V.54 test mode
XON/XOFF (software), RTS/CTS (hardware)
-11 dBm (dial-up—varies depending on country or region for which the
modem is set), -10 dBm (leased-line)
±0.01%
Chapter 1 – Product Description and Features
7
