Operating
1
Temperature
Humidity Range
Storage Temperature
Power Requirement
Power Supply
Requirement:
Dimensions
Weight
Limited Warranty
Certifications
Intelligent Features
1
UL Listed at 40° C, limited by power supply. UL Certification does not apply or extend to an ambient
above 40° C and has not been evaluated by UL for ambient greater than 40° C. "UL has evaluated this
device for use in ordinary locations only. Installation in a vehicle or other outdoor locations has not been
evaluated by UL. UL Certification does not apply or extend to use in vehicles or outdoor applications or
in ambient above 40° C."
Répertorié UL à 40° C, limitée par la puissance d'alimentation. Certification UL ne s'appliquent ni
s'étendre à l'une température ambiante supérieure à 40° C et n'a pas été évalué par UL pour ambiante
supérieure à 40° C. «UL a évalué cet appareil pour une utilisation dans des endroits ordinaires
seulement. Installation dans un véhicule ou d'autres emplacements en plein air n'a pas été évaluée par
UL.
La certification UL ne s'applique pas ou s'étendre à utiliser dans des véhicules ou les applications en
extérieur ou dans ambiante dépasse 40 ° C.
Multi-Tech Systems, Inc. MT5600BA-V92 User Guide
32°–120° F (0°–50° C) ambient under closed conditions
UL Listed at 40°C
25–85% (non-condensing)
14°– 185° F (-10° to +85° C)
9 to 12Vdc @ 650mA
Listed ITE power supply, marked "LPS" or "Class II",
output rated: 9 to 12Vdc, 650mA
6.2" wide × 1.4" high x 9.0" deep (15.8 cm × 3.6 cm x 22.9 cm)
2 lbs. (0.9 kg)
2 years
CE Mark
EMC: FCC Part 15 Class B, EN 55024, EN55002 Class B
Safety: cUL, EN 60950, UL 60950
Telecom: CS03, FCC Part 68, TBR21
Plug and Play; remote configuration for centralized setup and management;
pass-through and fixed callback security; AT command compatible; autodial,
redial, repeat dial; pulse or tone dial; dial pauses; auto answer; caller ID;
adaptive line probing; automatic symbol and carrier frequency during start-
up, retrain, and rate renegotiation; DTMF detection; call status display, auto-
parity and data rate selection; keyboard- and front panel-controlled modem
options; monitor and LCD displays for modem options; non-volatile memory;
storage of up to four command strings or telephone numbers of up to 40
characters each.
»
Chapter 3 – Using the Front Panel
7
