Parts List - BLADEZ Elliptical X-350p Owner's Manual

Elliptical trainer
Hide thumbs

Advertisement

Table of Contents
No.
Description
1
Handlebar end cap
2
Handlebar grip
3
T-Bar grip
4
Hand pulse grip unit
5
End cap
6
End cap
7
Locking washer
8
Washer
9
Sleeve
10
Sleeve
11
Washer
12
Nylock nut
13
Pedal tube shaft
14
Washer
15
Bearing
16
Retainer
17
Washer
18
Allen head bolt
19
Screw
20
Nylock nut
21
Plastic cap
22
Screw
23
Rear foot cover
24
Front foot cover (middle)
25
Front foot cover (left)
26
Front foot cover (right)
27
Wheel
28
Screw
29
Screw
30
Screw
31
Screw
32
Moter
33
Bearing
34
Bushing
35
Screw
36
Locking screw
37
Spacer
38
Screw
39
Washer
40
Screw
41
Nut
42
Spring
43
Meter
44
Washer
45
Screw
46
Nut
47
Flywheel
48
Speed Sensor Cable
49
Belt
50
End cap
Elliptical X-350P

PARTS LIST

No.
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84(A) Upper cover
84(B) Lower cover
85
86
87
88
89
90
91
92
93
94
21
Description
Drive pulley
Pedal, LH
Pedal, RH
Cap
End cap
End cap (T-Bar)
Middle cover, LH
Middle cover, RH
Screw
Screw
Magnet
Washer
Pulley
Base frame
Upright tube
Swivel tube, LH
Swivel tube, RH
Fixed handle bar
Handle bar, LH
Handle bar, RH
Pedal tube, left
Pedal tube, right
Front foot
Rear foot
Flywheel holder bracket
Belt ightener
Metal cross, LH
Metal cross, RH
Bushing
Bushing
Metal plate
Rubber Washer
Connecting tube
Console Cable 990MM
Console Cable inMiddle 550MM
Cable 850MM
Power Wire 750MM
Holder Base
Bottle Holder
Power Adaptor 9VDC 1A
Screws
Cable 420mm
Screws M4*25
